IEC Standard GDPQ-6000 Handheld 3 Phase Power Quality Analyzer
HV Hipot Electric Co., Ltd.- Size：263*168*65mm
- Weight：2.0kg
- Adapter Input：110V-240V, 50Hz
- Adapter Output：15V, 3A
- Battery：Chargeable Li-Polymer battery, 5000mAh
- Battery Working Hours：≥6h
Base Info
- Model NO.：GDPQ-6000
- Transport Package：Standard Plywood Case with Foam Inside
- Specification：ISO9001
- Trademark：HV Hipot
- Origin：Wuhan, China
- Production Capacity：5000set,Year
Description
Machine
Environment
Size
263*168*65mm
Working
Environment
0ºC~+45ºC, less than 90rh%
humidity
Weight
2.0kg
Storage
Environment
-20ºC~+50ºC, less than 95rh%
humidity (non-condensing)
Power Supply
Storage
Adapter Input
110V-240V, 50Hz
Type
TF card
Adapter Output
15V, 3A
Capacity
32G
Battery
Chargeable Li-Polymer battery, 5000mAh
Standard
Battery Working Hours
≥6h
Measuring Method
IEC 61000-4-30
Battery Charging
Time
Minimum 5h (25ºC ambient temperature)
Measuring Performance
IEC 61000-4-30 Class A
Power Saving
Adjustable LCD backlight brightness and standby time
Flicker
IEC 61000-4-15
Display
Harmonic
IEC 61000-4-7
Size
112.8×84.6mm
Power
Disassembly
IEEE 1459
Color
260k colors
Interference
Resolution
640×480
Between voltage input terminals
-60dB @ nominal frequency
Brightness
350 cd/m²(Typ.) Maximum brightness, adjustable brightness
Between voltage input terminal and current input
terminal
-95dB @ nominal frequency
Contrast
500:1 (Typ)
Common Mode Rejection
Viewing Angle
70/70/50/70 (Typ.)(CR ≥10) (left/right/up/down)
CMRR
>60dB
