Hj-3 Vibration System Agree Test Chamber Combine Climatic Chamber
Dongguan Hongjin Test Instrument Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Mass Scope of Workpiece：900kg
- Type：Vibration Testing Machine
- Accuracy Grade：0.5
- Loading Method：Dynamic Load
Base Info
- Model NO.：HJ-3
- Display：Digital
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Maximum Speed：2m,S
- Maximum Sinusoidal Excitation Force：3200kg.F Peak
- Maximum Random Excitation Force：3200kg.F
- Maximum Shock Excitation Force：6400kg.F
- Frequency Range (No Load)：2-2000Hz
- Maximum Displacement：51mm P-P
- Transport Package：Fumigation-Free Standard Export Wooden Box
- Trademark：Hongjin
- Origin：China
- Production Capacity：1000 Sets, Month
Description
Maximum load (sine) F=M.A10G (100 m/s2) 20G (200 m/s2) 30G (300 m/s2) Frequency 2000Hz±5% Payload 300kg Vibration isolation frequency 2.5Hz Moving coil diameter Ф335mm Moving coil quality 30kg Countertop screws 17×M10 Studio size D×W×H 800*800*800mm (width*height*depth) Dimensions D×W×H About 1800*2250*1700mm (W*H*D) Temperature range -40ºC~180ºC Humidity range 20%-98% Temperature fluctuation ≤±0.5ºC Temperature uniformity ≤±2ºC Temperature fluctuation ≤±3%R.H. Temperature uniformity ≤±3% Heating rate About 3.5ºC/min (no-load nonlinearity) Cooling rate About 1ºC/min (no-load nonlinearity)
