• Model NO.：GD-7305A
• Stirring Rate：(1500+-15)R,Min
• Dimension：550mm*340mm*720mm
• Net Weight：24kg
• Transport Package：Plywood
• Origin：Made in China
• HS Code：9031809090
• Production Capacity：100 Units , Month

Basic Info.

Model NO. GD-7305A Stirring Rate (1500+-15)R/Min Dimension 550mm*340mm*720mm Net Weight 24kg Transport Package Plywood Origin Made in China HS Code 9031809090 Production Capacity 100 Units / Month

Product Description

Automated Demulsibility Tester for Lubricating Oils


Introduction:

The Automated Demulsibility Tester is designed and made as per Standards GB/T7305 Petroleum oils and synthetic fluids - Determination of demulsibility characteristics, GB/T7605 Determination of demulsibility characteristics of turbine oils in service and ASTM D1401 Standard Test Method for Water Separability of Petroleum Oils and Synthetic Fluids.
The Automated Demulsibility Tester is suitable to determine the water separability of petroleum oils and synthetic fluids. It can be widely used in fields of petroleum, electricity, chemical industry , colleges and scientific research institutions.


Key Features:

1. The Automated Demulsibility Tester adopts small bath and desktop structure. It is easy to operate and good-looking. It is the improved product of our company.
2. It adopts electric motor to stir automatically. The temperature is accurate and uniform. It can do determination for 3 samples one by one.
3. The lifting of stirring device is convenient. The stirring paddle has good concentricity with cylinders. No tremble or touching the cylinder wall.
4. It adopts LCD to show the diagram. Intuitive and clear
5. Man-machine dialog. Menu type input.Easy to use.

Main Parameters:

1. Power supply:   AC(220±10%)V, 50Hz
2. Maximum power consumption:  2000W
3. Temperature range:  (Room temp.~ 99.9)ºC
4. Temperature control accuracy:  ±1ºC
5. Stirring rate:  (1500±15)r/min
6. Ambient temperature:  (15∼35)ºC
Relative humidity:   ≤85%
7.Dimension: 550mm×340mm×720mm
8. Net weight:24kg.

Note: If the required temperature is lower than room temperature,it can equip ZL-1 portable cooler manufactured by our company.
