• Model NO.：HS-YSJ5000
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Transport Package：Plywood
• Specification：530 * 290 * 490 mm
• Trademark：HST
• Origin：Shangdong, China
• HS Code：9024800000
• Production Capacity：1000

Basic Info.

Model NO. HS-YSJ5000 Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Under Transport Package Plywood Specification 530 * 290 * 490 mm Trademark HST Origin Shangdong, China HS Code 9024800000 Production Capacity 1000

Product Description




                                 HS-YSJ5000 Universal Crush Tester



1.INTRODUCTION:
This instrument can be used to test RCT,  ECT,  FCT,  PAT,  CMT.It's the basic equipment to test the compression strength. It adopts modern mechanical design and Micro computer processing technology, Touch-screen interface make it easy to operate. ARM chip have a big processing data function,and test data can be got directly
2.STANDARDS:
ISO 12192  ISO 3037  ISO 7263  ISO 3035  ISO11093-9  ISO12048  GB/T 2679.8  GB/T 6546  GB/T 6548  GB/T 2679.6  GB/T22874 GB/T22906.9  GB/T4857.3  GB/T4857.4
3.MAIN FEATURES:
3.1.The user can order corresponding accessories according to actual conditions, to achieve a variety of paper and cardboard strength test.
3.2.Servo motor control,low noise.high precise.
3.3.Advanced parts, use ARM chip, has the function of automatica reset, date memory, overload protection etc.
3.4.Test data can be printed out.
3.5.Mechatronics design, compact structure, nice appearance, easy maintenance.
4.MAIN TECHNICAL PARAMETERS:

Power supply	AC220V±10%   50HZ
Press measuring range	50~5000N
Resolution	1N
Accuracy	±1%
variability	≤1%
Speed	0~80mm/min
Platen size	300*300
Platen distance	300mm
Dimension	570*480*800mm
Net weight	85kg
