Xhgg502 Arc Tester Cable Fault Pre-Locator
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- After-sales Service：Technical Support
- Warranty：1 Year
- Test Mode：Saved Test
- Usage：Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
- Test Region：Forming Cable
- Power：Electricity
Base Info
- Model NO.：XHGG502
- Certification：CE
- Customized：Customized
- Color：Black
- Data Sampling Rate：60MHz, 120 MHz, 240MHz, 400MHz
- Test Distance：>60km
- Pulse Amplitude：400vpp
- Pulse Width：0.1us and 2us
- Transport Package：Wooden
- Specification：420mm× 250mm× 340mm
- Trademark：XZH TEST
- Origin：China Xi′an
- HS Code：854320100
- Production Capacity：100 Pieces ,Year
Description
Overview
Product Description
Product Features
Product Parameters
| Product name | Underground cable fault pre-locator(TDR) |
| Model | XHGG502 |
| MOQ | 1 Unit |
| Main function | For underground cable fault rough distance measurement |
| Data sampling rate | 60MHz, 120 MHz, 240MHz, 400MHz |
| Test distance | >60Km |
| The test cable length is set | <1Km (short distance);<3Km (medium distance);>3Km(long distance) |
| Pulse amplitude | 400Vpp |
| Pulse width | 0.1uS and 2uS |
| Reading resolution | 0.1m |
| system test accuracy | Less than 0.5m |
| Pulse coupler withstand voltage | 38kVDC |
| Working conditions | temperature -25ºC~+55ºC, relative humidity 85%, atmospheric pressure 750±30mmHg. |
| Measuring method | Low-voltage pulse method, high-voltage flashover method, multiple pulse method |
