1000KN Automatic Hydraulic High Quality Computer Control PC Display Servo Steel Bar Tensile Strength Universal Testing Machine with ASTM
Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.- After-sales Service：Quick and effective after sales service
- Warranty：one-year
- Type：Universal Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：TBTUTM-1000A
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- System：Oil tank
- Oil source cabinet dimension (mm)：1000x600x910
- Main unit dimension (mm)：960×620×2100
- Main unit net weight (Kg)：2200
- Transport Package：Standard Export Packing
- Specification：ISO
- Trademark：TBT
- Origin：Nanjing, China
- HS Code：90158790
- Production Capacity：50sets,Month
Description
Overview
Product DescriptionModel TBTUTM-100A TBTUTM-300A TBTUTM-600A TBTUTM-1000A Max. capacity(KN) 100 300 600 1000 Range 4%-100%F.S.(full range, without gear) Reading accuracy Grade 1 Error ±1% Resolution (F.S.) 1/200000F.S. Column Number 4 6 Width between two columns 345 430 515 510 Max tensile space(mm) 500 600 Max compression space(mm) 500 600 Bending test Distance between two points (mm) 100-270 100-350 100-400 Round specimen clamp diameter(mm) Ø6-Ø22 Ø10-Ø32 Ø13-Ø40 Ø20-Ø40 Flat specimen clamp thickness (mm) 0-15 0-40 Stroke (mm) 150 200 Pistons rise fastest speed(mm/min) 100 80 Beam rising speed (mm/min) 310 250 310 Displacement reading relative error ±1% Deformation reading relative error ±1% Motor capacity (KW) 2 2.5 Main unit dimension (mm) 665×490×1600 740×460×1900 850×560×2000 960×620×2100 Oil source cabinet dimension (mm) 1000×600×910 Main unit net weight (kg) 600 1200 1750 2200 Oil source cabinet net weight(kg) 250
