• Model NO.：KTS-200A
• High Temp. Chamber：+60 Oc~+200 Oc
• Low Temp. Chamber：-55 Oc~-10 Oc
• Pre-Heat Time：+60 Oc~+200 Oc Within 20mins
• Pre-Cold Time：+20 Oc~-55 Oc Within 60mins
• Test Chamber：-40 Oc~+150 Oc
• Controller：Touch Screen Controller Chinese and English Menu
• Safety Devices：No Fuse Breaker, Over Pressure, Over Heat and Over
• Transport Package：Strong Plywood Case, Meet International Standard
• Specification：Standard and customs made, ISO9001, SGS
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

SpecificationsNote:1. We reserve the right to change specifications without prior notice  2. Customized sizes and configurations availableModelKTS-A SeriesKTS-B SeriesKTS-D Series72A100A150A200A252A300A480A72B100B150B200B252B300B480B72D100D150D200D252D300DInterior sizeW(mm)450500600670700800800450500600670700800800450500600670700800H(mm)400450500600600600800400450500600600600800400450500600600600D(mm)400450500500600650750400450500500600650750400450500500600650Exterior sizeW(mm)14901540164017201750185018501490154016401720175018501850149015401640172017501850H(mm)17901840189020002000200022001790184018902000200020002200179018401890200020002000D(mm)16001700183018501930198025001600170018301850193019802500160017001830185019301980Test weight(KG)5101215182020510121518202051012151820Low Temp. chamber -55ºC~-10ºC -70ºC~-10ºC -80ºC~-10ºCPre-heat time +20ºC~-55ºC ,Within 60 min +20ºC~-70ºC ,Within 60 min +20ºC~-80ºC ,Within 60 mins Test. chamber -40ºC~+150ºC -55ºC~+150ºC -65ºC~+150ºCHigh Temp. chamber +60ºC~+200ºCPre-heat time +60ºC~+200ºC ,Within 20 minRecovery timeHigh-Temp Exposure 30 minLow-Temp Exposure 30 minRecovery time within 5 minSafety deviceNo fuse breaker, over pressureover heat and over current protection for compressor,over temperature protection,                            over load protection for blower, dry heat protectionStandard accessoryCable port(portΦ50mm)*1,   shelves*2Interior materialStainless steel plate(SUS 304)Exterior materialBaked painting steel or stainless steel(SUS304)Insulation materialRigid polyurethane Foam+glass fiber woolRefrigeration systemWater CooledSemi-hermetic compressor, cascade  refrigeration system, CFC free refrigerant(HFC-507 and HFC-23)ControllerPanel:7-inch LCD Touch panel,Chinese or English display selectableOperation model:Program or fix point runningMemory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles.Accuracy:Temp.:0.1% of F.S±1 digit     Humidity:0.1% of F.S±1 digitInput:Temp.:pt-100                Humidity:pt-100 or ~5V DCVAmbient Temp.+5ºC~+35ºCPowerAC 380±10%50Hz ,3 phase 4 wires +Ground Wires

Applicable Standards of Environment Test Chamber
The performance index conforms to the requirements of GB5170, 2, 3, 5, 6-95 'Inspection Methods for Basic Parameters of Environmental Test Equipment for Electric and Electronic Products-Low Temperature, High Temperature, Constant Temperature & Humidity and Alternating Temperature & Humidity Test Equipment'.
Basic Environmental Test Procedures for Electric and Electronic Products Test A: Low-Temperature Test Method GB 2423.1-89 (IEC68-2-1)
Basic Environmental Test Procedures for Electric and Electronic Products Test B: High-Temperature Test Method GB 2423.2-89 (IEC68-2-2)
Basic Environmental Test Procedures for Electric and Electronic Products Test Ca: Constant Temperature & Humidity Test Method GB/T 2423.3-93(IEC68-2-3)
Basic Environmental Test Procedures for Electric and Electronic Products Test Da: Alternating Temperature & Humidity Test Method GB/T423.4-93(IEC68-2-30)

Warranty: One-year free warranty for the whole set machine, lifelong time maintainance.
After-sale service: Feedback within 2 hours after getting the call.
Service: OEM service, Design service, Buyer label service.
Your attention will be highly appreciated.
We supply a 7*24 hour service.
