Laboratory Universal Salt Spray Testing Equipment

GUANGDONG BELL EXPERIMENT EQUIPMENT CO., LTD.
  • After-sales Service：24 Hours Online
  • Warranty：12 Months
  • Type：Salt Spray Testing Machine
  • Display：Digital
  • Control：Computer Control
  • Weight：100-500Kg

Base Info

  • Model NO.：BE-FH-SERIES
  • Power Source：AC380V
  • Volume：1440L
  • Internal Dimension：W1200xd1200xh1000mm
  • Outer Box Size：W2600xd1700xh1700mm
  • Temperature Fluctuation：±0.5ºC
  • Humidity Fluctuation：±2.5%Rh
  • Temperature Deviation：≤±2.0ºC
  • Transport Package：Each Set Protected with Resin Fiber and PP Film, T
  • Specification：Test Space1200x1200x1000(customizable)
  • Trademark：DGBELL
  • Origin：Guangdong China
  • HS Code：8419899090
  • Production Capacity：100set ,Month

Description

ModelBE-FH-SERIESVolume1200L               1440LInternal DimensionW1200xD1200xH1000mmOuter Box SizeW2600xD1700xH1700mmTemperature RangeLaboratory temperature range RT~50ºC,air saturated barrel temperature range RT~63ºC.Humidity Range20%RH~98%RH (the whole process can be controlled, look at the control accuracy ± 0.1RH%)
Humidity resolution 0.1%RHTemperature Fluctuation±0.5ºCHumidity Fluctuation±2.5%RHTemperature Deviation≤±2.0ºCHumidity Deviation(A)>75%RH:≤+2/-3%RH,(B)<75%RH:≤±5%RH.Temperature Uniformity≤2.0ºCTemperature Rise and Fall Overshoot<2ºCMaximum Load100KG batterySpray Volume1-2mL/80cm²1hr (at least 16 hours of collection, take its average)Spray Pressure1.00±0.01kgf/cm²
PH: Neutral 6.5~7.2
Acid 3.0~3.3Outer Box MaterialPVC corrosion resistant material, board thickness 8mm.Inner Box MaterialUsing PVC corrosion resistant material, board thickness 8mm.
Control mode: touch screen programmable control PLC, USB interface, with RJ485 interface connected to computer control. Special network control software, convenient for remote monitoring and data collection.Power Supply Voltage
 AC 380V 50HZ 9KW Laboratory Universal Salt Spray Testing EquipmentLaboratory Universal Salt Spray Testing Equipment

Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.

15+ years experience in test chambers manufacturing, High performance for your projects.

With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.
