• Model NO.：XB-OTS-S60
• Max.Acceleration(G)：17
• Uses：Vibration Testing Machine
• Amplitude(mm)：0~5
• Power：Electronic
• Direction of Vibration：Vertical or Level
• Warranty：One Year
• Certificate：Ce ISO
• Transport Package：Standard Strong Wood Case
• Specification：700*560*680 mm
• Trademark：OTS
• Origin：Guangdong, China (Mainland)
• HS Code：9031809090
• Production Capacity：248 Sets Per Month

Model NumberXB-OTS-S60Power:AC 220V/50Hz   ±2%Operating ambient temp:0~+45ºCperformanceMax.Load(kg):40kgFrequency range(Hz):3~200HzSweep-frequency range(Hz):3~200HzAmplitude(mm):0~5mmVibration direction:vertical and horizontalSet time range(s):1~350000 sWorking table size L.W.H(mm)450×450×43mmMachine size L.W.H(mm):1300×570×450mmControl chamber size L.W.H(mm:420×300×750mmPower(KVA):2.8Remark
 Set way: Chinese and English menu, computer operation, the use of specialized monitoring and control software,test of the whole process of handling and output.
Display functions: dynamic display test curves, multi-Dan, on the number of data.

Curve recorder features:real-time record of the test data,test data automatically,the test results can be stored, printed

Corresponding Standard:
IEC 68-2-6(FC),GB2423, JJG189-97, GB/T13309-91

Packing & Shipping


1.Strong standard wood case, inner plastic films wrapped for Vibration Testing Machine

2. Usually we delivery the equipment by air,by sea or by express. it depends on customer

Our Company
OTS (Overall Testing System)
Was established in 1978, with 35 years' history
With 30,000 square meter salable production base and 120 employees
Is one of the leading companies solely dedicated to manufacture of
Environmental Simulation Test Chambers ,Physical Testing Equipment .
(such as  constant temperature and humidity chambers, environmental chambers, climatic test chambers, rain and dust test chambers,thermal shock test chambers,fast change rate chambers, salt spray chamber,UV test chambers,walk in test chambers and other special customized test chambers  ;Tensile testing machine, vibration test machine ,carton compression testing machines, bursting strength testing machine etc.) ..
OTS has the equipment and expertise, with own R&D and consultant team, to meet and exceed your testing requirement.With offices in unrivaled quality advantage, dynamic management team with superb manufacturing process,also the quality with the world norms:ISO , ASTM, DIN, EN, GB, BS, JIS, ANSI, UL,CE, TAPPI, AATCC, IEC, VDE...


FAQ:
Q1 :Can you customize the product?
A:Yes, we can customize any products according to requirements.Hot selling lab electronic temperature humidity cabinet/Environmental climate test chamber also can be customized.
Q2 :How to choose the most suitable products?
A:Our professional team will give you the best suggestion,just be  patiently to tell us the information about the parameters your required.
Q3 :Can you arrange installations and commissioning in our lab?
A:Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate
Secondly;We had detailed operation manual with chamber , any problems you can find and solve in it
Thirdly, some of customized chambers we should to install and teach your team to operate .
