Test Equipment Vacuum Oven for Industrial Motor Performance Test

Guangdong Yuanyao Test Equipment Co., Ltd.
  • Type：Material Testing Machine
  • Maxcapacity：<1000KN
  • Accuracy Grade：0.5
  • Load Way：Mechanical Load
  • Loading Method：Dynamic Load
  • Display：Needle

Base Info

  • Model NO.：YPO480
  • Control：N,a
  • Weight：100-500Kg
  • Power Source：AC380V
  • Inner Size：800*1000*600mm
  • External Size：1200*1700*840mm
  • Volume：600 Liters
  • Temp. Fluctuation：+,-0.3 Degree
  • Color：Ivory
  • Interior Chamber Material：SUS#304 Stainless Steel Plate
  • Exterior Chamber Material：Stainless Steel Plate + Powder Coated
  • Circulation System：Circle Fan
  • Indication Resolution：0.1degree , 1 Degree
  • Heat up Time：60 Mins
  • Transport Package：Well Packed in Strong Wooden Cases.
  • Specification：YPO-600
  • Trademark：Yuanyao
  • Origin：China
  • HS Code：9032100000
  • Production Capacity：100 Sets , Month

Description

Room Temperture+25ºC~200ºC(Max.400ºC)Vacuum degreeNormal pressure to 3K Pa(Min 5 Pa can be customizedTemperture.fluctuation±0.3ºCControl.resolution0.1ºCHeating up timeRT + 25~200ºC<90minRT + 25~400ºC<120minExternal chamber materialCold rolled sheet+power coatingInternal chamber materialSUS#304 Stainless steelInsulationFiberglass woolHeating systemSUS#Stainless steel high-speed heaterControlling systemButton type digital display controllerVacuum systemVacuum pump+ solenoid value + vacuum gaugePower supplyAC 3ψ 380V 60/50HzCustomization serviceNo-standard or special requirements are all welcome
