• Model NO.：YWER-8000
• Humi. Fluctuation：+,-2.5%Rh
• Color：Ivory
• Interior Chamber Material：SUS#304 Stainless Steel Plate
• Exterior Chamber Material：Stainless Steel Plate + Powder Coated
• Insulation System：PU&Fiberglass Wool
• Wind Circulation System：Siroco Fan
• Transport Package：Strong Plywood Case
• Specification：CE, SGS, TUV certified.
• Trademark：Yuanyao
• Origin：China
• HS Code：9032100000
• Production Capacity：10 Sets,Month

Non-standardExterior chamber sizeW×H×D(mm)Temperature range0ºC;-20ºC;-40ºC;-60ºC,-70ºC~+70ºC(+80ºC)Humidity range30% RH~95%RHTemp.Humi fluctuation±0.3ºC;±0.5%RHTemp.Humi uniformity±3ºC;±5%RHIndication Resolution Temperature:0.01 humidity:0.1%RHHeat-up and  Cool-down timeHeat-up:2ºC/min(Average),cool-down time 1ºC/min(Average)Air cirulation system Centrifugal fan air circulation systemHeating system SUS#Stainless steel high-speed heaterHumidification systemElectrothermal steam humidificationRefrigeration systemCompressor + Finned evaporator + Air (Water) cooled condenserDehumidifying systemDew point dehumification methodControlling systemTouch screen controller+SSR+PIDExterior chamber materialCold rolled plate + Powder coatingInterior chamber material SUS#304 Stainless steelInsulation material PU +fibergalss woolcomponentsVacuum glass observation window
Test hole (50mm)
Control status indicator
Interior light Safety protection device Overheat protection circuit breaker
 Humidification system overheat protection
 Compressor overload protection
 Control system overload protection
 Overload indicator
 Phase sequence protection
 Water shortage protection
 High voltage and low voltage protection
 Over temperature protection
 Water supply delay protection
 Fan overcurrent protectionPower supplyAC 3Ψ380V 60/50Hz (Power supply can be customized)Customization serviceNon-standard or special requirements are all welcome




Except Customized size drive-in climate control test room, Guangdong Yuanyao Test Equipment Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Automatic dispenser robot, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

More details about the specification, please contact Angela Cheng, thanks for your attention.
