Climate Simulation Xenon Arc Light and Weather Fastness Tester
Ai Si Li (China) Test Equipment Co., Limited- Certification：CE, TUV, ISO
- Warranty：1 Year
- Tube Using Life (H)：1500h
- Illumination Intensity：340nm ~Full Spectrum
- Tube Power：1kw,6kw
- Sunlight Exposure Cycle：0.01~999 Hours 59mins
Base Info
- Model NO.：XL-1000
- Bpt：40~120degree C(+,-3degree C)
- Spray Water Flow (L/Min)：1~2.4
- Internal Dimension W*H*D (mm)：900*900*900
- External Dimension W*H*D (mm)：1500*2000*1400
- Transport Package：Plywood Case
- Specification：CE, ISO
- Trademark：ASLi
- Origin：Guangdong, China
- HS Code：85141090
- Production Capacity：30 Sets,Month
Description
XL - 1000Internal Dimension
W*H*D (mm) 1000*1000*1000
External Dimension
W*H*D (mm) 1550*2150*1550
Tube Using Life (H) 1500 Tube Power 1KW/6KW Illumination Intensity 340nm
0.35~0.6w/m2 Full spectrum
1200±200w/m2 Lighting Filter Type Inner filter Quartz Outer filter Quartz Simulated Test Status Test samples: Explore under outer space Cooling System Water cooled or wind cooled Temperature Control
Range of the Test Cabinet Black panel temperature : BPT 40~120degree C(±3degree C) Black standard temperature :BST 38~120degree C(±3degree C) Humidity Control
Range of the Test
Cabinet Humidity when lighting: 20%R.H.~75%R.H. (± 5%R.H.) Humidity when dark: 60%R.H.~95%R.H. (± 5%R.H.) Rotating Speed of
he Samples Holder(RPM) 1~5 adjustable Diameter of Sample
Shelf(mm) 500±50 Sunlight Exposure Cycle 0.01~999 hours 59mins Raining Period/ Time Raining Period:1~240mins,discontinuous-type, adjustable Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa Spray water flow(L/min) 1~2.4 Explore Area(cm2) 7500 Power AC 380 V(±10%),50/60HZ ,3 phase 5 Lines
Xenon arc Light Fastness Tester Features:
1. Advanced design technology and concept,
2. Excellent technology of producing and outstanding system of quality management,
3.can be the most realistic simulated solar spectrum, including ultraviolet, visible and infrared.
4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. To determine the color fastness and aging to sunlight, weather resistance, etc.
Certificate of these the machine:
China official 3rd party calibration report
CE certiification
For the package:
1. PP film first
2. Vacuum package
3. PP film again
4. 10mm thickness PU foam to avoid collision
5. stronged plywood case
6. Standard ASLI CASE MARK
