• Model NO.：YT-ZL
• Weight：0-100Kg
• Power Source：AC220V
• Measuring Range：10~500n
• Sample Clamping Force：900n
• Resolution：0.1 N
• Size (L*W*H)：455mm*425mm*280mm
• Transport Package：Wooden Box
• Trademark：YANTE
• Origin：Hangzhou, China
• HS Code：9024800000

Basic Info.

Model NO. YT-ZL Weight 0-100Kg Power Source AC220V Measuring Range 10~500n Sample Clamping Force 900n Resolution 0.1 N Size (L*W*H) 455mm*425mm*280mm Transport Package Wooden Box Trademark YANTE Origin Hangzhou, China HS Code 9024800000

Product Description

Zero Span Tensile Tester is used to test the zero span tensile strength of paper and cardboard. Cardboard factories, carton factories and carton users are usually used to test the tensile strength of corrugated paper. This instrument is an ideal auxiliary test tool for papermaking companies, cardboard manufacturers, carton manufacturers, carton users, and quality supervision and inspection departments.

Application Range

Pulps.Determination of zero-span tensile strength,wet or dry§


Product Features

The instrument adopts high-precision weighing sensor, ball screw and guide shaft, and the transmission is stable and accurate.Using stepping motor, low noise, precise controlARM processor, 24-bit imported analog-to-digital converter, improve the response speed and test accuracy of the instrument.Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.Real-time display of the curve of tension change during the test.Cooperate with computer software for communication (purchased separately).

Technical Parameters


No.	Parameter item	Technical index
1	Power Supply	AC(220±10%)V, 50/60Hz 50W
2	Working Environment	Temperature(10~35)ºC, Humidity≤ 85%
3	Display	7 inch color touch screen
4	Measuring range	(0.1~250)N,(0.1~500)N
5	Indication error	±1%(Range 5%~100%)
6	Indication resolution	0.01N
7	Test speed	(25±2)N/S
8	Return speed	30mm/min
9	Work Capacity	(0~6)mm(adjustable)
10	Chuck width	(15±0.01)mm
11	Print	Built-in thermal printer
12	Communication Interface	RS232(Default) (USB, WIFI optional)
13	Dimension	470×440×320 mm
14	Net Weight	37kg around



Executive Standard

GBT 26460-2011


Supporting Accessories And Consumable


No.	Accessory name	Model	Picture	Standard	Optional
1	Standard Distance Cutter	YT-Q15			√
2	Punch Standard Distance Cutter	YT-CQ15			√
3	Adjustable Paper Cutter	YT-TJD300			√
