GDCR2000G+ Clamp Ground Resistance Tester
HV Hipot Electric Co., Ltd.- Power supply：6V DC
- Protection level：Double insulation
- Structural features：Clamp CT
- External magnetic field, electric field：<40A,m, <1V,m
- Single measurement time：0.5 s
- Resistance measurement frequency：>1kHz
Base Info
- Model NO.：GDCR2000G+
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HVHIPOT
- Origin：Wuhan China
- Production Capacity：2000PCS,Year
Description
Resistance
0.010Ω-0.099Ω
0.001Ω
±(1%+0.01Ω)
0.10Ω-0.99Ω
0.01Ω
±(1%+0.01Ω)
1.0Ω-49.9Ω
0.1Ω
±(1%+0.1Ω)
50.0Ω-99.5Ω
0.5Ω
±(1.5%+0.5Ω)
100Ω-199Ω
1Ω
±(2%+1Ω)
200Ω-395Ω
5Ω
±(5%+5Ω)
400-590Ω
10Ω
±(10%+10Ω)
600Ω-880Ω
20Ω
±(20%+20Ω)
900Ω-1200Ω
30Ω
±(25%+30Ω)
Specification
Model
GDCR2000G+
Storage
99 groups
Sound and light alarm
"beep--beep--beep--" alarm sound, press the AL button to open, close
Power supply
6V DC (4 section of No.5 alkaline dry battery)
Working environment
-20ºC~55ºC; 10%RH~90%RH
LCD screen
4 digital LCD display, 47mm*28.5mm
Jaws size
Long jaw: 65*32mm, round jaw: diameter 32mm
Jaw open size
Long jaw 35mm; round jaw 32mm
Clamp weight
Long jaw 1160g; round jaw 1120g (with battery)
Clamp size
Long jaw: length and width 285mm * 85mm * 56mm
Round jaw: length and width 260mm * 90mm * 66mm
Explosion-proof mark
Exia II BT3 Ga
Protection level
Double insulation
Structural features
Clamp CT
Shift
Fully automatic shifting
External magnetic field, electric field
<40A/m, <1V/m
Single measurement time
0.5 s
Resistance measurement frequency
>1KHz
