• Model NO.：GD-4132
• Power Source：AC220V
• center frequency：400Hz
• bandwidth：200Hz
• Signal gain：80dB
• power：Built-in Li-battery, nominal voltage 7.4V, capacit
• Transport Package：Standard Export Wooden Box
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan, China
• HS Code：9030899090
• Production Capacity：5000set,Year

Basic Info.

Model NO. GD-4132 Power Source AC220V center frequency 400Hz bandwidth 200Hz Signal gain 80dB power Built-in Li-battery, nominal voltage 7.4V, capacit Transport Package Standard Export Wooden Box Specification ISO, SGS Trademark HV Hipot Origin Wuhan, China HS Code 9030899090 Production Capacity 5000set/Year

Product Description

Portable GD-4132 underground Cable Fault Locator

It including main unit, acoustic and magnetic sensor, anti-noise headphone and charger.
It is suitable to test all kinds of power cable with metallic conductor.
Its main function is locating poor insulation point, detecting circuit and depth of power cable.

Features

1. Acoustic Magnetic receiving at the same time,
2. Strong anti-interference ability
3. With anti-noise headphone.
4. 320*240 LCD screen display
5. Built-in big capacity Li-battery, with fast charger.
6. Acoustic and Magnetic signal waveform display, signal and noise is easy to distinguish.
7. Using cursor to measure acoustic and magnetic delay, accurately determine fault point.
8. According to initial polarity of magnetic.waveform, it can locate and route detection.

Specifications


1. Locating function

a. Acoustic signal transmission band: center frequency 400Hz, bandwidth 200Hz
b. Signal gain: 80dB
c. Locating accuracy: 0.1m


1. Power Supply

1. Built-in Li-battery, nominal voltage 7.4V, capacity 3000mAH.
2. Power consumption: 300mA, continuous working time > 9hours.
3. Charger: input AC220V±10%, 50Hz. Nominal output 8.4V, DC 1A
4. Charging time:<4hours



1. Dimension: 270mm*150mm*210mm
2. Weight: 1.5kg.
3. Use condition: Temperature -10ºC--40ºC, humidity 5-90%RH, altitude <4500m
