100kg Load Fabric Tensile Strength Tester
Dongguan Haida Equipment Co., Ltd.- Warranty：One Year
- Type：Tensile Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
Base Info
- Model NO.：HD-B609B-S
- Display：Computer Display, Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Standards：ASTM JIS Cns Pstc
- Motor：Servo Motor
- Delivery Time：15 Days After Receive The Deposit
- Power：One Phase, AC 220V
- Load Resolution：1,250, 000
- Accuracy：0.5%
- Sensor：Celtron Load Cell
- Test Speed：0.01 to 500 mm,Min
- Display Device：LCD or PC
- Transport Package：Strong Wooden Case
- Specification：Design Standards: GB,T16491; GB,T1040; GB,T1041; G
- Trademark：Haida
- Origin：Dongguan, China
- HS Code：9024109000
- Production Capacity：150 Sets Per Month
Description
Product Features
1. Motor system: Panasonic servo motor +Servo driver +High precise ball screw (Taiwan)
2. Control system: a, computer control with TM2101 software; b, Back to origin automatically after the test, c, store data automatically or by manual operation
3. Data transmission: RS232
4. Displacement resolution: 0.001mm
5. Graph scale automatic optimization can make graph to display with best measurement and can implement graphics dynamic switching in the test and has force-elongation, force- time, elongation -time, stress - strain.
6. It can save results automatically after test finished, and it is manual filing. It can display maximum force, yield strength, compressive strength, tensile strength, elongation, peel interval maximum, minimum and average, etc.
7. User can set parameters of product material such as length, width, thickness, radius, area and so on.
8. Many languages random switching: Simplified Chinese, Traditional Chinese, and English.
Company Information:
After-service:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
