• Model NO.：THR-3000-C
• Cooling Mode：Air, Water Cooling
• Refrigerants：R404A
• Display Mode：LCD Display Touch Control
• Temperature Range：-20~150c
• Test Port：Dia.50mm
• Application：Bicycle Accessories
• Transport Package：Standard Wood Case
• Specification：OEM Available
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：85143000
• Production Capacity：45 Sets Per Month

ModelF-TH-150(A~F)F-TH-225(A~F)F-TH-408(A~F)F-TH-800(A~F)F-TH-1000(A~F)Internal Dimension WxHxD( mm)500x600x500600x750x500600x850x8001000x1000x8001000x1000x1000Internal Dimension WxHxD (mm)1100x1750x16001200x1800x17001250x1900x19001600x2050x21501700x2200x2300Range of Fast Temperature ChangeTemperature Range: -70~+150ºC; Range of Fast Temperature Change: -45~+85ºC; Max. temperature rising/falling speed is 15ºC/min when the whole process with linear control .Humidity Range(Optional)20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional ,need Dehumidifier)Indication resolution/Distribution Uniformity of Temperature and Humidity0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H.Control Accuracy of Temperature and Humidity±0.5ºC; ±2.5% R.H.Temperature Rising/Falling Velocity

Rising/Falling Speed Rate with linear control : 3~15ºC/min, adjustable

Rising/Falling Speed Rate non-linear control : 3~30ºC/min, adjustable

MaterialInterior material is SUS 304# stainless steel,exterior is stainless steel or SEE cold-rolled steel with paint coated.Insulation MaterialResistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materialsCooling SystemWater cooled/single segment compressorProtection DevicesFuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protectionOptional AccessoriesInner door with operation hole(Optional), Water Purifier, DehumidifierCompressorFrench Tecumseh Brand, Germany Bizer BrandPowerAC380V 3∮ 5 lines, 50/60HZApprox. Weight(Kg)250350450600700

Inner door with operation hole (optional)
50mm or100mm Entrance hole for test wire, Dia.50mm or 100mm
Sample Shelves, two layers
RS-232 or RS-485 communication

Rapid temperature changes test chamber features:

1. Graceful appearance, circularly shaped body, surface treated with mist strips. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for observation of sample under test,with interior lights
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. French Tecumseh is used as compressor, with environment friendly refrigeration R23,R404A
6. LCD display screen is used for the control unit, capable of displaying set point and actual point at the same time
7. The control unit has the functions of multiples segment program editing
8. Quick or ramp rates control of temperature and humidity.
9. Casters are provided for ease of mobility, with strong positioning screws.



Warranty: one year free warranty for whole set machine,lifelong time maintainance.

After-sale service: feedback within 8 hours after get the call or email.

Service:OEM service,Design service,Buyer lable service.

Certificate of these the machine:

China official 3rd party calibration report

CE certiification



For the package:

1. PP film first

2. Vacuum package

3. PP film again

4. 10mm thickness PU foam to avoid collision

5. stronged plywood case

6. Standard ASLI CASE MARK

More products:

Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. Rapid temperature changes test chamber, Fast Temperature Impact Test Machine is our star products , and we had obtained the CE certification for this machine .

If you have any question about those temperature humidity test chamber for it , please contact with us ,thank you
