• Model NO.：DH-PM
• OEM：Yes
• Transport Package：Standard Exporting Wooden Package
• Specification：400mm*200mm*200mm
• Trademark：DahoMeter
• Origin：Dongguan, Guangdong
• HS Code：9027809900
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. DH-PM OEM Yes Transport Package Standard Exporting Wooden Package Specification 400mm*200mm*200mm Trademark DahoMeter Origin Dongguan, Guangdong HS Code 9027809900 Production Capacity 300 Sets/Month

Product Description

Gas Hydraulic Supercharged Punching Machine / Instrument / Equipment / Apparatus / Device





The pneumatic hydraulic press type punching machine is a multifunctional special equipment. A gas-liquid booster cylinder system is used. Suitable for blanking and pressing for metal, non-metallic materials, The machine is easy, quick and labor-saving, and has good stability.



Technical Specification

• Working gas source pressure: 0.4-0.8Mpa
• Pre-pressing force: 2000N
• Boost output: 10000N
• Maximum punching thickness: 12mm
• Punch diameter: 80mm
• Punching stroke: 40mm
• Workbench size: 260mm*280mm
• Dimensions: 340mm*300mm*700mm



During the stamping process, after placing the rubber compound, do not adjust the position of the rubber material at will, and do not put your hand under the punch to avoid accidents.



• Turn on the power. Connect the gas source to the machine and work when the pressure is expressed to 0.4-0.8Mpa.
• Put the required cutting tool such as the cutter into the punch connecting hole, lock the tool, and place the sample or the test piece on the work surface made of plastic plate. A yellow cardboard or magazine is placed on the table to help cut and protect the cutting edge from damage.
• Press the red "power switch" to turn on the power.
• Press the "Preload Increase and Decrease Switch" to pressurize, the punch falls, and the sample is punched.
• Press the "supercharge increase/decrease switch" to increase the press pressure.
• At this time, complete the stamping, press the "supercharge increase/decrease switch" to reduce the pressure, and then press the "pre-pressure increase/decrease switch" to lift the punch, that is, complete a stamping, and the sample can be taken out.
• Regularly refuel the pressure reducing valve.
• Apply dustproof cover after use to prevent oil and dust from entering.
• When punching the sample, be sure to put a cardboard or plastic plate under the sample.

Packaging & Shipping:




Company Information:


We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.
