Twin Columns Digital Display Electronic Utm Universal Testing Machine (100N-600KN)
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：24-Hour After-Sale Technical Support, Mail, Video
- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Maxcapacity：<1000KN
Base Info
- Model NO.：WDS-200
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
- Control：Manual Control
- Weight：500-1000Kg
- Power Source：AC220V
- Delivery Time：15 Days After Get Payment
- Certification：ISO SGS Ce
- Transport Package：Standard Exporting Packing
- Specification：1000*650*2150mm
- Trademark：HST or OEM
- Origin：Shandong China
- HS Code：9024101000
- Production Capacity：100 Sets Per Month
Description
StructureFour-column floor or desk model, (upper is compression and lower is tensile) Cover All aluminum alloy Control method Computer control Load accuracy Class 1(Class 0.5 for choice) Load range 2%~100%F.S (0.2%~100%F.S for choice) Load resolution 1/300000 Rang of deformation 4%-100%FS Resolution of deformation 0.04um Accuracy of displacement Within ±0.5% of indicating load Resolution of displacement 0.01mm Test speed(mm/min) 0.05-1000 0.05-500 0.05-500 0.05-200 0.05-200 Tensile space(mm) 800 700 700 550 700 Compression space(mm) 800 700 700 550 700 Test width(mm) 400 500 550 600 500 Thickness of beam(mm) 30 58 68 108 200
