Test Instrument

Safety Helmet Impact Testing Machine

Dongguan Hong Tu Instrument Co., Ltd.
  • Type:Impact Puncture Testing Machine
  • Accuracy Grade:0.5
  • Display:Digital
  • Control:Manual Control
  • Weight:0-100Kg
  • Power Source:AC220V

Base Info

  • Model NO.:HT-3011
  • Impact Head Hemispherical:Diameter 96mm
  • Transport Package:Stronger Wooden Case
  • Specification:GB2811 standard
  • Trademark:HOTOTECH
  • Origin:Dongguan
  • HS Code:9013809000
  • Production Capacity:100 Sets Per Month

Description

Basic Info.

Model NO. HT-3011 Impact Head Hemispherical Diameter 96mm Transport Package Stronger Wooden Case Specification GB2811 standard Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 100 Sets Per Month

Product Description

Safety Helmet Impact Testing Machine

Purpose
It is specialized in testing helmet's impact and penetration resistance, set up the wooden head model with safety helmet on high sensitivity sensor, then impact from height of 1 m by 5kg steel hammer, and test the instantaneous force valve of impact by high sensitivity's force sensor device to determine the helmet's impact absorption performance is good or not, the penetration resistance test can be standard after changing the impact hammer, and up to GB2812 standard, LCD display

Parameter
1. Steel hammer weight: 5± 0.01kg
2. Impact head hemispherical: Diameter 96mm
3. Weight of impact hammer of penetration resistance: 3± 0.05kg
4. Cone angle of impact hammer: 60 angle
5. Cone radius of the hammer: 0.5mm
6. Impact model: Directed down
7. Test force range: 0-60000N
8. Wood head form: One each of 2 number and 5 number, in line with the requirements of GB2811 appendix A
9. Force sensor: Precise piezoelectric type
10. Display: LED digital display, keep biggest force automatically
11. Frequency response range: 5-1000HZ
12. Lifting device: Electric hoist, upper and lower limit

Company Introduction
  Dongguan Hong Tu Instrument Co.,Ltd specializes in developing and producing testing machines and our company established in 2006 year , we have firm connection and full cooperation with China's National Third-party Quality Inspection and Notarization Center on producing and developing high-precision testing machines
  We treasure the value of good quality , reasonable price and efficient service with customer satisfaction. we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit

Safety Helmet Impact Testing Machine
Steel hammer weight  5±0.01kg
Impact head hemispherical  diameter 96mm
Weight of impact hammer of penetration resistance  3±0.05kg
Cone angle of impact hammer  60 angle
Cone radius of the hammer  0.5mm
Impact model   directed down
Test force range0-60000N
wood head formone each of 2 number and 5 number , in line with the requirements of GB2811 appendix A
Force sensor  Precise piezoelectric type
Display  LED digital display,keep biggest force automatically
Frequency response range5-1000HZ
lifting device  Electric hoist , upper and lower limit
