• Model NO.：TPJ-10
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Delivery Time：2 Days After Get Payment
• Max Testing Force：10kn
• Testing Frequency：0-5Hz
• Power：10kw
• Max Sample Length：400mm
• Max Sample Diam：300mm
• Transport Package：Standard Export Packing
• Trademark：HST
• Origin：China
• HS Code：9031809090
• Production Capacity：9000 Sets Per Year

Basic Info.

Model NO. TPJ-10 Loading Method Dynamic Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Delivery Time 2 Days After Get Payment Max Testing Force 10kn Testing Frequency 0-5Hz Power 10kw Max Sample Length 400mm Max Sample Diam 300mm Transport Package Standard Export Packing Trademark HST Origin China HS Code 9031809090 Production Capacity 9000 Sets Per Year

Product Description

electro-hydraulic servo spring fatigue testing machine
Application:
This machine is mainly used for various spiral spring, disc springs and shock absorbers, seal springs, and the fatigue life of test. Widely used in spring, shock absorbing production, application, etc.

Technical parameter:

Model	TPJ-10
Max testing force	10KN
Max sample length	400mm
Max sample diam	Φ300mm
Testing frequency	0~5Hz
Amplitude	Max:100mm
Counter capacity	999999999
Working voltage	220VAC/50Hz
Power	10kW

 Main features:
1. According to the technical requirements of the spring, adjust the amplitude and frequency of spring
2. LCD,testing time and frequency according to requirements can be input program,finished testing automatically.
3. Preset testing time ,automatic stop
4. Easy operation,working stability.

Enough outstanding technical engineers , Skilled workers, large non-dust workshop, 16 years experience, 10 years' vendor of many famous test brands in the world, ISO and CE certificated, 2.5 hours reach Qingdao port, this is how we keep superior quality and competitive offers for global valued customers.
For more informations, please contact Sunny for help.+86-15866777590
