30 Ton Compression Testing Machine for Cement
Jinan Kason Testing Equipment Co., Ltd.- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Compression Testing Machine
- Maxcapacity：300kn
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：YAW-300B
- Loading Method：Static Load
- Display：Computer
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：None
- Control and Deal Mode：Computer Constant Control and Auto Dealing
- Range of Test Force：2% ~100%
- Load Speed：0.1~9.9kn,S
- Pisto：80mm
- Compression Platen Size：160mm
- Compression Test Space：180mm
- Transport Package：Standard Polywood Package
- Specification：950*700*1900mm
- Trademark：HST
- Origin：Shandong China
- HS Code：9024800000
- Production Capacity：800set, Month
Description
1 class
Test measurement range
4%-100%FS
Load accuracy
Better than ±1%
Control way
Computer control auto loading progress
Piston stroke
80mm
Distance between upper and lower platen
180mm
Test space adjustment method
Block adjustment test space
Max distance between the right and
left columns
190mm
Size of upper and lower platen
180mm
The distance between the upper and
lower anti rupture fixture
/
180mm
Anti rupture oil cylinder stroke
/
50mm
Size
1200×550×1400mm
All the machines can be customized according to your special requirements.
Contact:Sunny telephone/whatsapp/line :+8615866777590
