• Model NO.：TLW-5
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：None
• Test Accuracy：1 Class
• Test Force Test Arrange：2%~100%
• Displacement Resolution：0.01mm
• Speed Relative Error：+-1%
• Transport Package：Standard Export Packing
• Specification：550× 400× 1600mm
• Trademark：HST
• Origin：China
• HS Code：9031809090
• Production Capacity：900 Sets Per Month

Single column, double spaces(lower tensile,upper compression)Control methodComputer controlTest accuracy1 classTest force test arrange
(F·S)2%~100%F·STest force value relative error≤±1%Displacement value relative error≤±1%Displacement resolution0.01mmDeformation value  relative error≤±(50+0.15L)umSpeed adjust range0.001-500mm/min(stepless speed regulating) Speed relative error≤±1%Effective tensile spaceStandard: 600mm  Heighten: 850mmEffective compression spaceStandard: 600mm  Heighten:850mmPressure plate size110mmUpper and lower platen parallelism≤0.05mmPower supplyAC220V±10%,50HzDimension550×400×1600mmWeightAbout 100kg
Main Features:
1.Automatically clearing: test force, displacement, according to the needs to be cleared at any time;
2.Automatic shifting: automatic switching the appropriate range to ensure accuracy load;
3.Automatic calibration: system can automatically realize the accuracy of the calibration value
4.Control method:You can achieve a variety of control method, test force, test speed, displacement, etc., with the following features:
a) Setting the test force P,  detect the spring deformation F;
b) Setting the deformation F,  detect the spring test force P;
c) Setting the test force P, detect the remaining height of the spring ( or the tensile length of the tensile spring) H,
d) Setting the spring remaining height of the spring, ( or the tensile length of the tensile spring) H, detect the spring test force P; Can set the pre-compression height of the pre-compressed spring , the number of pre-compression can be arbitrarily set;
e) Setting max10 detection points (can be set into the return detection);
f) The detection of the spring deformation is in contact with the work pressure plate shall prevail, then the test should have the reaction force, the size of the test force (ie, the initial force) arbitrarily set;
g) The deformation caused by the sensor can be compensated. The deformation caused by the sensor and stiffness of the machine does not affect the accuracy of displacement.
With function of automatic stop when overload ;
5.Breakage judgment: sample after fracture,beam automatic stop moving
6.Limiting protection: Program control and Mechanical limiting protection.

For more informations, please contact Sunny for help.+86-15866777590
