• Model NO.：GD-01005
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Limiting Oxygen Index Tester
• Item Name：ASTM D2863 Oxygen Index Tester
• Application：Measure The Min. Oxygen Concentration to Support C
• Applicable Standards：ASTM D 2863, ISO 4589-2, Nes 714
• Usage：Let User Know Min. Oxygen Concentration as Necessa
• Oxygen Concentration Measurement Range：0-100%
• Features 1：England Original Paramagnetic Type Oxygen Sensor
• Features 2：Can Communicate with PC, Printer
• Features 3：High Accuracy, Stable, Reliable
• Gross Weight：30kg
• Warranty：1 Year
• Transport Package：Packed in Veneer Case
• Specification：Refer to detailed description
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：10 Sets, Month

Basic Info.

Model NO. GD-01005 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Limiting Oxygen Index Tester Item Name ASTM D2863 Oxygen Index Tester Application Measure The Min. Oxygen Concentration to Support C Applicable Standards ASTM D 2863, ISO 4589-2, Nes 714 Usage Let User Know Min. Oxygen Concentration as Necessa Oxygen Concentration Measurement Range 0-100% Features 1 England Original Paramagnetic Type Oxygen Sensor Features 2 Can Communicate with PC, Printer Features 3 High Accuracy, Stable, Reliable Gross Weight 30kg Warranty 1 Year Transport Package Packed in Veneer Case Specification Refer to detailed description Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 10 Sets/ Month

Product Description

 ASTM D2863 Oxygen Index Tester

Introduction:
The critical oxygen index tester is suitable for determining the minimum oxygen concentration required to maintain the combustion test under the specified test conditions in the mixture of oxygen and nitrogen. The analyzer is equipped with an imported mass flow controller, which provides accurate measurement and durability. Used to evaluate the combustion performance of homogeneous solid materials, laminates, foams, films, and films under specified conditions.

Features:

1. Adopts England original Servomex Paramagnetic type oxygen sensor, which accuracy can be up to +/-0.1%;
2. The sensor is better than the traditional electrochemical sensor because it doesn't need to change oxygen battery, so, it has long lift time more accurate and faster response time.
3. Equipped with 2pcs Mass Flow Controller(MFC) to control N2 and O2 mixing ratio;
4. Equipped with high-temperature quartz glass tank;
5. Equipped with supported and unsupported sample clamps;
6. Equipped with portable ignition device, gas tank connector, accurate pin valve to adjust the flame;
7. Digital setting N2 and O2 concentration;
8. Computer+LABVIEW software to control N2 and O2 mixing ratio, read O2 concentration in mixing chamber, and store&print out test results;
9. Reserve a calibration port to calibrate the sensor;
10. Stainless steel air channel design, equipped with one way fire-resistance valve, magnetic valve, a fine filter, so, it is stable and safe;
11. Patented design gas mixing chamber, which ensures the gases can mix the gases in short time, data is more accurate;

Specification:


Item Name	ASTM D2863 Oxygen Index Tester
Oxygen concentration measurement range	0-100%
Resolution	0.1%
Accuracy	+/-0.2%
Response time	<300ms
Oxygen stability time	<30s
Oxygen concentration sensor	England Servomex Paramagnetic type oxygen sensor, accuracy:+/-0.1%
Gas displacement	50L/S
Size	600(W)*310(D)*545(H)mm
Workbench size	1500(W)*600(D)*800(H)mm
Weight	30kg
Power supply	AC 220V, 50/60Hz, 5A

International Standards:
ASTM D 2863, ISO 4589-2, NES 714
Our Service:

Pre-sale Service:

• The inquiry will be replied within 24 hours.
• Welcome to visit our factory.
• Technical data and operation manual sent for evaluation.

After-sale Service:

• Training how to install the machine, training how to use the machine at our factory;
• Engineers available to service machinery overseas at customers' cost;
