SF6 Gas Vacuuming and Filling Equipment SF6 Refilling Device
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Accuracy Grade：1
- Load Way：Electronic Load
- Display：Digital
- Weight：0-100Kg
- Power Source：AC 3 phase,4 core 380V±10%, 50Hz
Base Info
- Power supply：AC 3 phase,4 core 380V±10%, 50Hz
- Power(KW)：1.5
- Vacuumizing port：M2 7×1.5 three channels for option
- Pumping speed(m3/h)：55
- Ultimate vacuum(absolute pessure PA)：10
- Initial pressure of vacuumizing：53kPa
- Final pressure of vacuumizing：30PA
- Recharge speed：5m3,h
- Vacuum measuring type：Pointer vacuometer
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9027809900
- Production Capacity：2000PCS,Year
Description
Basic Info.
Power supply AC 3 phase/4 core 380V±10%, 50Hz Power(KW) 1.5 Vacuumizing port M2 7×1.5 three channels for option Pumping speed(m3/h) 55 Ultimate vacuum(absolute pessure PA) 10 Initial pressure of vacuumizing 53kPa Final pressure of vacuumizing 30PA Recharge speed 5m3/h Vacuum measuring type Pointer vacuometer Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027809900 Production Capacity 2000PCS/YearProduct Description
SF6 Gas Vacuuming and Filling Equipment SF6 Refilling DeviceOverview
The model GDQC-501H is mainly used for vacuumizing and vacuum degree testing during installing, running and maintaining procelain SF6 breakers of 35-220kV, CT/PT and other SF6 equipment. It is a compact device, all filling and vacuumizing device is installed on a rugged metal carframe. It is easy to move even on macadam road.
Product Composition
Vacuum pump, 24hours continuous working without heating and losing vacuum degree.
Pointer vacuometer
Regulating valve
Gas pipe
The required valve for SF6 breaker maintenance
Control part
Specifications
| Rotary-vane vacuum pump Brand | Domestic brand [2xz-15B] |
| Cooling type | long-time working with air cooling type for vacuum pump |
| Moving type | With wheels, moving by humanpower(light) |
| Working principle | high pressure ball valve, vacuum gague assists vacuum pump to vacuumizing |
| Pumping speed(m3/h) | 55 |
| Ultimate vacuum(absolute pessure Pa) | 10 |
| Initial pressure of vacuumizing | 53kPa |
| Final pressure of vacuumizing | 30Pa |
| Recharge speed | 5m3/h |
| Vacuum measuring type | Pointer vacuometer |
| Measure range of vacuuometer | 0-103pa |
| Yearly leakage rate | ≤1% |
| Working temperature | upper limit: +40ºC lower limit: +5ºC, -10ºC, -30ºC |
| Noise | ≤60dB SPL |
| Power supply | AC 3 phase/4 core 380V±10%, 50Hz |
| Power(KW) | 1.5 |
| SF6 special ball valve | high pressure vacuum dual purpose ball valve(13.5MPa, no leakage) |
| Vacuumizing port | M2 7×1.5 three channels for option |
| Steel wire braiding rubber hose will be supplied before leaving factory | M27×1.5×10m/piece |
| Weight(kg) | 66 |
| Size (mm) | 800*560*770(or reference) |
| Appearance color | Silver gray |
