Gd-F8010 Engine Coolant Foam Tendency Testing Equipment ASTM D1881

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Type：Kinematic Viscometer
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Under

Base Info

  • Model NO.：GD-F8010
  • Transport Package：Wooden Case
  • Specification：300mm*340mm
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：200units,Month

Description

Power supplyAC(220±10%)V, 50Hz

Applicable standard:

SH/T0066 ASTM D1881.

Digital display temperature control:

88±1ºC.

Air flow rate:

1000±25ml/min

Working unit:

Two-hole operation.

Pressure adjustment:

flow meter adjustment.

Mixing method:

motor mixing

Heating method:

Heater heating



Main technical specifications



1.Stainless steel frame can put and fix 2 cylinders without steel ring to avoid floating.There are 2 accurate flow meters and 1 control box includes all electron devices.



2. Stainless steel frame can be tested 88ºC.



3.There is a mixer on heating bath of glass jar.



4.Stainless steel heater.



5.Accurate and adjustable flow meter with connection of needle valve, supporting rackand exsufflator.



6.Two 500ml measuring cylinders with graduation and rubber stopper; in addition, airinlet and outlet pipe is set on the top.



7.Micro-computer controller with PID function and digital display temperature (permanent display during test) whose accuracy is 0.1°C;

in addition, it has Pt100 RTD temperature probe.



8.Contact control box is very convenient.



9.Maintain the mixed solution of coolant and water at 88ºC±1ºC constantly, and use steady airflow to ventilate for 5min to test the foam volume and its extinction time





Exhibition

We have developed sales channels in many countries such as the UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan,

India, Germany, Belgium, the USA, Mexico, Kenya, Nigeria, South Africa, and other countries worldwide. And we have

gained a strong advantage and high reputation in the international market.

After several years' development, our products have become highly intelligent and wide coverage.
And our company has become one of the leading manufacturers of petroleum testing instrument and electrical testing

instrument.

Brazil ANALITICA LATIN AMERICA 2017 Photos Show

Gd-F8010 Engine Coolant Foam Tendency Testing Equipment ASTM D1881

Packing

Goods are packed in veneer case, which is firm and safe for overseas shipment.
Gd-F8010 Engine Coolant Foam Tendency Testing Equipment ASTM D1881
