Canton Meeting Request Environmental Test Chambers
Guangdong Komeg Industrial Co., Ltd.- Control System:Touch Screen Controller
- Interrior Material:Honed SUS304 1.0mm
- Temp. Range:-20oc~+150oc or -68of~+302of
- Humidity Range:20-98%R.H.
- Temp. Constancy:+,-0.5oc
- Humidity Constancy:+,-2.5%R.H.
Base Info
- Model NO.:KMH-225S
- Equipment Power:12.8kw
- Heat up Time:-20 Oc~+100 Oc Within 35mins
- Pull Down Time:+20 Oc~-20 Oc Within 45mins
- Type:Material Testing Machine
- Weight:100-500kg
- Power Source:AC380V
- Transport Package:Strong Plywood Case, Meet International Standards
- Specification:Standard and customized, ISO9001, SGS, CE, TUV, UL
- Trademark:KOMEG
- Origin:Dongguan, China
- HS Code:90321000
- Production Capacity:1000 Sets,Year
Description
ModelKMH-225S 225L chamber volume Temp. range -70°C ~150°C Display resolution 0.1°C Temperature stability High±0.5°C ,low ±1.0°C Temperature uniformity ±2.0°C Heat up time -70°C ~+100°C,within 60 min Pull down time +20°C ~-70°C,within 80 min Humidity range 20~98%R.H,(standard), '10~98%R.H,(with humidifier) Humidity constancy ±2.5%R.H Humidity uniformity ±3.0%R.H Interior Dimension(mm) 700W*700H*480D Exterior Dimension(mm) 980W*1890H*1460D Interior material Stainless Steel Plate(SUS 304) Exterior material Baked Painting Steel Or Stainless steel(SUS304) Insulation material Rigid polyurethane Foam and Glass Fiber Wool Total power 8.5KW(heater 3KW included) Max current 17.6A Water Consumption 0.7L/hr Ambient Temp. +5°C ~+35°C Power Supply AC 380V±10%50Hz ,3 phase 4 wires +Ground Wires Weight 330KG Sight window size 430*530mm Sample holder 2 pcs Fittings cable port(portΦ50mm)*1, chamber lamp*1, power cable *2m Safety device (standard) No fuse breaker,over pressure,over heat&over current protect,over temp. protect, over load protect for blower, dry heat protect Control System Balanced Temperature & Humidity Control (BTHC)System Refrigeration system Air Cooled (Water Cooled is option) Hermetic compressor Hermetic compressor Single stage refrigeration system, CFC-Free refrigerant(HFC-507/HFC-23) CFC-Free refrigerant(HFC-507/HFC-23) Controller 7-inch LCD Touch Screen panel Operation model :Program or fix point running Memory capacity :120programs,1200steps, All repeat 999 cycles, part repeat 99 cycles Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available
