100A Transformer DC Winding Resistance Test Set
HV Hipot Electric Co., Ltd.- Output current：100A, 50A, 20A, 10A, 5A
- Min. resolution：0.1μΩ
- Accuracy：±(0.2%+2digits)
- Relative humidity：<90%RH(no condensing)
- Size：440*245*395mm
- Weight：instrument: 19.5kg; accessory case: 7.5kg
Base Info
- Model NO.：GDZRC-100U
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- Production Capacity：3000 Sets,Year
Description
Output current
100A, 50A, 20A, 10A, 5A
Min. resolution
0.1μΩ
Measurement range
At 100A: 50μΩ~100mΩ;
at 50A: 100μΩ~200mΩ;
at 20A: 200μΩ~800mΩ;
at 10A: 500μΩ~2Ω;
at 5A: 1mΩ~4Ω
Accuracy
±(0.2%+2digits)
Working temperature
0ºC~40ºC
Relative humidity
<90%RH(no condensing)
Size
440*245*395mm
Weight
instrument: 19.5kg; accessory case: 7.5kg
Accessories
Tester
1 set
Power cord
1pc
Test line
1 set
Printing paper
1 roll
Fuse
2pcs
Ground cable
1pc
RS232 communication line
1pc
Test object
1pc
User's guide
1 copy
Warranty card
1 copy
Factory test report
1 copy
