• Model NO.：GD-H1087
• Power Source：AC220V
• CCS：Cold-Cranking Simulator for Apparent Viscosity
• ASTM D5293：for Apparent Viscosity of Engine Oils and Base Sto
• Apparent Viscosity：Apparent Viscosity of Engine Oils
• Refrigeration Method：Semiconductor Refrigeration
• Cycle Mode：Multi-Function Universal Steel Pump
• Temperature Control Mode：Digital Display Pid Temperature Controller
• Detection Method：Automatic Test, Automatic Temperature Rise
• Result Processing：Automatic Storage, Calculation
• Temperature Control Range：Normal Temperature ~-35c
• Warranty：1 Year
• Transport Package：Plywood
• Trademark：GOLD
• Origin：Chongqing of China
• HS Code：9031809090
• Production Capacity：200PCS,Month

Basic Info.

Model NO. GD-H1087 Power Source AC220V CCS Cold-Cranking Simulator for Apparent Viscosity ASTM D5293 for Apparent Viscosity of Engine Oils and Base Sto Apparent Viscosity Apparent Viscosity of Engine Oils Refrigeration Method Semiconductor Refrigeration Cycle Mode Multi-Function Universal Steel Pump Temperature Control Mode Digital Display Pid Temperature Controller Detection Method Automatic Test, Automatic Temperature Rise Result Processing Automatic Storage, Calculation Temperature Control Range Normal Temperature ~-35c Warranty 1 Year Transport Package Plywood Trademark GOLD Origin Chongqing of China HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

Cold Cranking Simulator (CCS) for measuring the apparent viscosity of engine oils



Introduction of  Cold-Cranking Simulator:

1. The Cold cranking viscosity simulates the viscosity of an oil in crankshaft bearings during cold temperature start up.
2. The cold cranking simulator (CCS), ASTM D5293, correlates with engine cranking speed at low temperatures.
3. The Cold Cranking Simulator is a relatively favorable, fast, and accurate instrument for measurement of motor oil viscosity at low temperatures.


Features of Cold-Cranking Simulator:

1. Automatically detect the rotational speed and control current to reduce human error.
2. Semiconductor refrigeration, large cooling capacity.
3. The Cold Cranking Simulator adopts the imported motor drive, high precision.
4. The LCD screen shows all working status.
5. It can connect to the printer to print the results.
6. Automatically calculate results after calibration with standard oil.
7. Microcomputer control, Windows operating system, full Chinese/English interface.
8. Improved rotor, low torque test state, high repeatability.
9. Automatically generate a calibration curve, directly display the test viscosity results.
10. All test processes are fully automatic control, no manual operation is required, the test stops automatically and the temperature rises.
11. The instrument automatically recommends the cooling temperature.
12. The rotary encoder detects the rotational speed.
13. Viscosity measurement range: 1500~15,000CP.
14. It can edit dozens of standard oil results.
15. Equipped with special low temperature refrigeration equipment.


Specifications of Cold-Cranking Simulator:


1	Applicable standards	GB/T6538, ASTM D2602, D5293
2	Refrigeration method	Semiconductor refrigeration
3	Cycle mode	Multi-function universal steel pump
4	Temperature control mode	digital display PID temperature controller
5	Detection method	Automatic test, automatic temperature rise
6	Result processing	Automatic storage, calculation
7	Temperature control range	Normal temperature ~-35ºC±0.03
8	Working power supply	AC220 V, 50Hz
