• Model NO.：YAW-300B
• Loading Method：Static Load
• Display：Computer
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V,380V
• Oil Cylinder Position：Under
• Accuracy：1 Class
• Piston Stroke：80mm
• Upper/Lower Plate Displacement：180mm
• Plate Size：180mm
• Transport Package：Standard Sea Shipping Case
• Specification：630*457*1410mm
• Trademark：Hensgrand or OEM
• Origin：Shandong, China
• HS Code：9024800000
• Production Capacity：5000 Sets,Month

Overview Product Description

1. Applications:

YAW-300B  Computerized Automatic Brick Compression Testing Equipment/ Concrete Building Material Testing Equipment is mainly designed for testing the compression strength of cement and mortar.  It can fulfill the test automatically according to the requirements, which lists in the inspection method for the strength of cement and
 mortar, also possess the below advantages, such as: realizing screen display of test data and test curves. It is ideal inspection equipment for factories, laboratory and education, etc.
2. Features:
2.1 Computer control up, down, test, stop and loading progress
2.2 Computer automatically control the loading progress
2.3 This machine consist of the host machine, oil source and control system.
2.4 High precision digital servo valve with closed-loop control function
2.5 Can realize the load rate, such as load or stress rate loading
2.6 Can auto printing
3. Specifications1 classTest measurement range4%-100%FSLoad accuracyBetter than ±1%Control wayComputer control auto loading progressPiston stroke80mmDistance between upper and lower platen180mmTest space adjustment methodBlock adjustment test spaceMax distance between the right and
left columns190mmSize of upper and lower platen180mmThe distance between the upper and
lower anti rupture fixture /180mmAnti rupture oil cylinder stroke/50mmSize1200×550×1400mm
