• Model NO.：HD-A505S-1200
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC220V
• Capacity (Optional)：5 Ton
• Power：1phase, 220V, 50Hz
• Warranty：One Year
• Test Space (L*W*H)：1000*1200*1200mm
• Motor：Servo Motor
• Load Accuracy：≤0.5%
• Speed of Compression：10 ± 3 Mm,Min
• Dimension (L*W*H)：2370*1500*2100mm (Can Be Custom Made)
• Operation Mode：PC
• Load Resolution：1,250, 000
• Transport Package：Strong Wooden Case
• Specification：Tappi-T804, JIS-20212, GB4857.3.4, ASTM-D642
• Trademark：Haida
• Origin：China
• HS Code：9024800000
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. HD-A505S-1200 Control Computer Control Weight 500-1000Kg Power Source AC220V Capacity (Optional) 5 Ton Power 1phase, 220V/ 50Hz Warranty One Year Test Space (L*W*H) 1000*1200*1200mm Motor Servo Motor Load Accuracy ≤0.5% Speed of Compression 10 ± 3 Mm/Min Dimension (L*W*H) 2370*1500*2100mm (Can Be Custom Made) Operation Mode PC Load Resolution 1/250, 000 Transport Package Strong Wooden Case Specification Tappi-T804, JIS-20212, GB4857.3.4, ASTM-D642 Trademark Haida Origin China HS Code 9024800000 Production Capacity 50 Sets Per Month

Product Description

                    Computer Servo Control Carton Compression Test Instrument


Specifications:
1.Up to TAPPI-T804, ASTM-D64
2.Box compression tester
3.Computer servo control system

Applications:
Corrugated board boxes and Cartons, Plastic Packaging, Wooden box
STANDARDS:
Meets ISO2872ISO2874GB/T4857.3GB/T4857.4
The Usage of Carton Compression Test Instrument:

Introduction:
Box compression tester is used to test the compression strength, bending strength ,proof pressure, deformation and stowage for flexible packaging cases , corrugated cases, honeycomb crates, and other packaging cases


Features of Computer Servo Control Carton Compression Test Instrument:

1. Using a single-screen operation; do not need to switch the screen;

2. With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily;

3. Adopting windows platform, and all the parameter settings can be processed in the dialog box, and it operates easily;

4. The pattern of Test reports can be self-designated; test data can be displayed directly in the main screen;

5. Choosing translational, comparative mode at the same time to make a number of curve data comparison;

6. With a variety of measurement units, Measure In Imperial & Metric are switchable;

7. With self-return & auto-correction function;

8. With automatic magnification function, in order to achieve the most appropriate size of the graphics;

9. With the user-defined Test methods; with experimental data analysis function;

10. It can do test of compression, bending, pressure holding & fatigue.


Specifications of Carton Compression Test Instrument:
(The table parameters for the company Standard Model parameters, we support customer customization parameters)

Model	HD-A505S-1200
Unit (switchable)	Kg, Lb, N
Capacity (optional)	5 T
Load Resolution	1/250,000
Load Accuracy	≤0.5%
Test Space (L×W×H)	1000×1200×1200mm
Speed of Compression	10 ± 3 mm/min
Operation Mode	PC
Report Items	Serial number, Peak value, Average value, Designated holding pressure value; all memorable
Structure	Panasonic Servo Control System (Japan); Ordinary screw rod ;4 sensors; LED display
Dimension (L×W×H)	2370×1500×2100mm (can be custom made)
Power	1ø, 220v/ 50Hz
Weight	Approx. 850kg
Safety Devices	Overload protection, overvoltage protection & limited position protection device
Standard	TAPPI-T804, JIS-20212, GB4857.3.4, ASTM-D642

The Introduction Of Haida
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.




Haida After-sale Service:
1.Warranty: 1 year free warranty (Nature disaster and human damage expect)
2. Trouble figure out: Feedback with 2 hours after get the call, offer solution case and help to solve the problem in 8 hours.

Package info.: PP film first, 10mm thickness foam ( between machine and plywood case), And then strong plywood case.
