• Model NO.：HYCZ-1
• HS Code：90248000
• Production Capacity：50sets,Month

Basic Info.

Model NO. HYCZ-1 HS Code 90248000 Production Capacity 50sets/Month

Product Description

WHEEL TRACKING MACHINE
Features:
1. This tester is used to test the high-temperature wheel rutting ability of asphalt mixture for the high-temperature stability performance of related mixing proportion design.
2.This tester is made with with an embedded WiFi,  advanced single-chip microcomputer controlling technology, machine finishing technology and related new developping application software.
3. Automaticly control temperature and time. Display displacement change, record the curve and print the result table automaticly.
4. Adopt absolute temperature sensor to collect temperature.
5. Adopt high precision displacement sensor and temperautre sensor.
6. This machine is equipped with one piece personal computer with Win-8 English operating system and one piece printer.

Model	HYCZ-1
Heating Power	3000W
Driving Motor Power	750W
Electrical supply	380V
Specimen size	300x300x50mm or other require dimension
Working Method	crank connecting rod driven test wheel movement
Rubber wheel hardness	84±4   international standard
Test wheel moving distance	230mm±10mm
Load cycles	26.5±1 cycles/min
Loading device	the contact pressure is 0.7±0.05Mpa when the temperature is 60oC, total loading is around 78kg and adjustable
Deformation measurement precision	0.3%
Temperature control precision	0.5ºC
Working temperature	0~80oC    humidity≤90%, haven't corrosive and flammable gas
Weight	500Kg
