High Voltage Impulse Voltage Generator for Lightning Impulse Full Wave Testing
Sansion Power Electric Co., Ltd.- Accuracy Grade:0.5
- Display:LCD
- Control:Computer Control
- Power Source:380V,220V110V at Cutomized
- Nominal Voltage:200kv or at Customized
- Rated Energy:10kj or at Customized
Base Info
- Model NO.:SXCF
- Impulse Capacitance:0.5UF or at Customized
- Each Stage:100kv 0.25UF or at Customized
- Transport Package:Plywood Cases
- Trademark:Sansion Power
- Origin:Wuhan, China
- HS Code:9030339000
- Production Capacity:100 Sets, Year
Description
Basic Info.
Model NO. SXCF Impulse Capacitance 0.5UF or at Customized Each Stage 100kv 0.25UF or at Customized Transport Package Plywood Cases Trademark Sansion Power Origin Wuhan, China HS Code 9030339000 Production Capacity 100 Sets/ YearProduct Description
High Voltage Impulse Voltage Generator
1. Voltage utilization factor: Standard lightning impulse voltage waveform ≥90% when load capacitance is below 1000pF, standard operation impulse voltage waveform≥80% when load capacitance is below 2000pF. Standard operation impulse voltage waveform ≥70%.
2. Locking range: level voltage is within the range of 20%-100% rated voltage, positive and negative locking range no less than 25%.
3. Out-of-control rate of synchronous discharge: <5%
4. Min. output voltage: ≥±20% of rated voltage.
5. Instability of discharge voltage: <±1.0%
6. Continuous time: Above 2/3 of rated voltage, continuous working when charge and discharge once every 120s. Below 2/3 of rated voltage, continuous working when charge and discharge once every 60s.
7. Nominal voltage: ±200kV
8. Impulse capacitance: 0.5µF
9. Number of stages: 2
10. Rated stage voltage: ±100kV
11. Rated energy: 10kJ
12. Rated stage capacitance: 1µF(each impulse capacitor 1µF at 100kV, total 2pcs)
Impulse voltage waveform: generated when load capacitance is 300-3000pF
More details please contact Sansion Power by email for further information.
