• Model NO.：GDYD-M
• Current Accuracy：≤1.5% (F.S)
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030339000
• Production Capacity：1000PCS,Year

Basic Info.

Model NO. GDYD-M Current Accuracy ≤1.5% (F.S) Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030339000 Production Capacity 1000PCS/Year

Product Description

Features

1. Digital display panel mounted controls & indicators with easy to read legend.
2. Monitoring high voltage side voltage, low voltage side current and indicator of zero, power, working start, timing.
3. Over-current protection, zero-starting protection, sound and light alarm.
4. Continuously variable output from zero to full voltage.
5. With new type time relay, time range is more wider (1S ~ 99H).
6. Using the latest current relay, more accurate and reliable.
7. All equipment equipped with wheels, easy to move.

Technical Parameter

Power Supply	AC 380V±10%; 50Hz±1Hz;(Other frequency or voltage can be customized.)
Output voltage	0-100kV,AC
Capacity	20kVA
HV Source	: SF6 gas filled transformer (Gas type testing transformer)
Output control	Manual control
Voltage accuracy	≤1.5% (F.S)
Current Accuracy	≤1.5% (F.S)
Timing range	0-99H
Metering	Digital display, kV meter: 0-100kV, mA meter:0-200mA
Humidity	85% RH
Environmental temperature	-20ºC~50ºC
Weight	Control Unit: About 90kg 20kVA/100kV gas testing transformer: about 90kg
