Iform Laboratory Foam Bitumen Plant Used for Cold Mix Materials
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Transport Package：Wooden Case
- Specification：0.5CBM
- Trademark：C-TECH
- Origin：China
Base Info
- Model NO.：iFOAM
- HS Code：90248000
- Production Capacity：10sets Per Month
Description
Basic Info.
Model NO. iFOAM HS Code 90248000 Production Capacity 10sets Per MonthProduct Description
The iFOAM Laboratory Foam Bitumen Plant is designed to be professional equipment as a true representation of "Asphalt Foaming", a professional-grade equipment for indoor study of foamed asphalt. iFOAM supported use of the mixer can be used for cold mix materials, but also for hot mix(warm mix) materials.
Model form:
Water consumption: Min: 2.5L/Hour
Max: 6.0L/Hour Air consumption:
Min: 0L/Hour Max: 100L/Hour
Max bitumen pump pressure: 2.5Mpa
Max water pressure: 0.6Mpa Air pressure:
Min: 140Mpa Max: 170Mpa
Water Temperature: Min: 10°C Max: 60°C
Bitumen tank volume: 12.5L
Power supply voltage: 220V
Water tank volume: 6L Air chamber Volume: 6L
Air chamber Volume: 6L
Rated power Bitumen pump: 1.5kW
Heaters: 3.2kW
Control: 0.1kW
Bitumen pump speed: Min: 1Hz
Max: 60Hz
Power supply voltage: 220V
Asphalt foam spraying time can be set: 0.1-999S
Dimension (lengthxwidthx height): 1261x670x1200mm
