• Model NO.：CTM-01
• HS Code：90248000
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. CTM-01 HS Code 90248000 Production Capacity 100 Sets/Month

Product Description

30 or 50KN CBR testing machine

standard: BS 1377, 1924; EN 13286-47;ASTM D1883; AASHTO T193

    This machine is suitable for test of soils and mix materials (the grain size of the soil is less than 40mm) compacted with CBR mold so as to confirm the bearing loading ability of pavement, roadbed subcrust as well as material layer of the roadbed to be designed. It consists of a twin column frame, proving ring, penetration bar, loading plate, micrometer, measuring device for swell increment etc. and easy to operate.


Specifications:
Capacity: 30 KN/50KN (selectable)
Load speed: 1.0 mm/min
Penetration bar: dia. 50 mm x 100 mm
Platen: dia. 170 mm
Platen travel: 50 mm
Mold: dia. 152 mm x 170 mm
Dimension: 310 x 310 x 930 mm
Power: 220 V, 50 Hz
Weight: 80 Kg

Accessories
34-T0093 Dial gauge tripod
34-T0092/A Aluminium swell plate
34-T0092/B Brass swell plate
34-T0095/B Split surcharge weight 2 kg,
2.27 kg selectable
Above accessories order separately.
