• Model NO.：FAV-01
• HS Code：90248000
• Production Capacity：10 Pieces,Month

Basic Info.

Model NO. FAV-01 HS Code 90248000 Production Capacity 10 Pieces/Month

Product Description

Fully automatic single-station vicat tester




VICATRON X
Automatic Control Data System
New Generation BLUETOOTH System
Standard : EN 196-3, 13279-2, 480-2, ASTM C191, C187.
• The Computer-controlled, VICATRON X can be used to determine the initial and final setting time of cement, mortar pastes and gypsum.
• This single-station apparatus automatically monitors the setting process and provides output curves of the process.
• The test sequence is programmable and tests can be performed in air or in the water test kit.
• With programmed test sequences, the unit provides automatic registration of initial set and final set times, as well as providing setting plots of the entire sequence.
• The automatic VICATRON X apparatus is a last generation equipment, which enables automatical execution of tests according to the following standard methods:
• Automatic Vicat Apparatus is to be supplied complete with EN Initial and Final needles.
• Fully Automatic Vicat apparatus for setting time test on cement/mortar/gypsum.
• The Automatic Vicat Apparatus must execute the test program using a fully automatic test cycle.
• With Firmware in the unit which enables (min) five user test profiles to be established.
• Unlimited storage of test results.
• VICATRON X - PC software, enables users to manage test data including graphing and report generation
• The timed cycle of events is to be operator-selectable and penetrations can be selectable at intervals of 30 seconds, 1,5, 15 or 30 minutes
• Fully automatic controlled directly from Tablet PC as no need to use digital screen
• Test procedures can be customized and stored to match user-defined requirements
• Large test space with easy accessibility
• Auto calculation of initial and final setting time at programmable penetration depth limits
• ADVANTAGES
• Fully Automatic Single Station System for Fast Results
• Can check on pc software that needle finished points with red coloured & not finished points are empty.
• New Generation BLUETOOTH system
• After the test you can mail directly which you selected mail address.
• Easy to test user friendly
• High Precision & Accuracy of penetration as 0.001 mm
• Unlimited data storage.
• Produces temperature vs penetration (or deflection) for individual stations in real time.
• Automatic computer piloting according to the test standard chosen
• Can do test in water
• Recall mode permits viewing of previously saved results and performs database maintenance.
• TECHNICAL DETAILS
• • Direct Tablet PC controlling saving time for storage or print out
• • Easy programming of customized test profiles, recallable for future tests, including:
• • Adjustable test start delay
• • Penetration points positions
• • Manual or automatic penetration rate
• • Free or driven dropping mode
• • Holding intervals inside the sample
• • Automatic end- test detection
• • Automatic measurement of initial and final setting time
• • Test data: test number, operator, client, date, hour, cement type, delay
• • Easy calibration menu
• • Clock calendar
• • Multi-language
• • Penetration measurement by encoder
• ACCESSORIES
• 8" TABLET PC                                             1
• VICATRON X - PC Software                      1
• Final Needle                                                1
• Initial Needle                                               1
• Glass Plate                                                  1
• Vicat Mould - EN or ASTM                          1
• Cylindrical probe for consistency test     1
• Additional weight 700 g                             1
• Power: 220 V, 50 Hz, 1 ph
• Weight approx.: 20 kg
