30kV/1kVA AC Hipot Test Equipment (Oil Type)
HV Hipot Electric Co., Ltd.- Type：Withstand Voltage Test Set
- Maxcapacity：0-300kv
- Accuracy Grade：1.5%
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：GDYD-M
- Control：Manual Control
- Weight：100-500Kg
- Power Source：AC220V
- Input：AC220V ± 10%
- Frequency：50Hz,60Hz ± 1Hz
- Output：0-30kV, 33mA AC RMS
- Capacity：1kVA
- Working Duration：100% Rated-1minute, 50%-continuous
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：2000PCS,Year
Description
Basic Info.
Model NO. GDYD-M Control Manual Control Weight 100-500Kg Power Source AC220V Input AC220V ± 10% Frequency 50Hz/60Hz ± 1Hz Output 0-30kV, 33mA AC RMS Capacity 1kVA Working Duration 100% Rated-1minute, 50%-continuous Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Specifications
| Input | AC220V ± 10% |
| Frequency | 50Hz/60Hz ± 1Hz |
| Output | 0-30kV, 33mA AC RMS |
| Working Duration | 100%Rated-1minute, 50%-continuous |
| Capacity | 1kVA |
| HT Source | Oil type testing transformer |
| Output control | Manual control |
| Voltage accuracy | < 1.5% (F.S) |
| Current Accuracy | < 1.5% (F.S) |
| Timing range | 0-99H |
| Metering | Digital display, kV meter: 0-30kV AC, mA meter:0-33mA AC, A meter:0-5A AC |
| Humidity | 85% RH |
| Environmental temperature | -20ºC~50ºC |
| Weight Control unit | about 20kg |
| Dry testing transformer | about 50kg |
