• Model NO.：YSRT-1728-E
• Testing Standard：IEC60529, IEC60598, GB4208, GB700001
• Time Setting Way：Controller Set
• Color：Stainless Steel,Ivory
• Distance From Nozzle to Shell：2.5--3m
• Test Grade：Ipx5&Ipx6 Flush Test
• Application：Light,Lamp, Auto Parts, Electronics, etc.
• Transport Package：Strong Wood Carton
• Specification：IEC60529
• Trademark：Yuanyao
• Origin：China
• HS Code：9031809090
• Production Capacity：100 Sets,Month

SpecificationModelYSRT-1728-AYSRT-1728-E(IEC-529)(CNS14165) Internal Dim.WHD(mm)1200×1200×12001200×1200×1200 External Dim.WHD(mm)1750×1850×13001750×1850×1300 Water Temp.NormalNormal
Spray Type
Total water
 flow(L/min)R11.8IP×1With in 1--1.5mm/min(In drip box)R23.2IP×2With in 3--3.5mm/min(In drip box)S124.5IP×3angle±600,R:400mm,1.1L/minS239.2IP×4angle±1800,R:400mm,1.8L/min
Preesure of
spray nozzle
(kgf/cm 2 )R10.11.Flow rate of the water=0.07L/min
2.IP×3,Radius:400mm,Number or open holes=16,total water flow:1:1L/min.
3.IP×4,Radius:400mm,Number or open holes=25,total water flow:1:8L/min.
*Radius:200mm,R400mm.(For IP×3,IPx4)R20.3S11S23(RPM)Test Specimen Frame17RPM1RPM
   Spray Nozzle Rotation Speed23RPM
Swing 60°from vertical for 4 seconds at one time

Swing 180°from vertical for 12 seconds at one time
   Material InteriorSUS#304 Exterior Other ComponentsChamber lamp.Wiper
casters with AdjustersChamber lamp.Wiper,casters with Adjusters Power Source[K.W]AC 1Ψ 220V 60/50Hz 4KW

Except Cameras shell IPX5 rain proof test equipment , Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.



Welcome to enquire and purchase and visit our factory to talk the agent cooperation affairs.
