• Model NO.：YPOC-1000
• Loading Method：Static Load
• Display：Digital
• Control：Controller
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：N,a
• Inner Size：800*1000*600mm
• External Size：1300*1700*840mm
• Volume：72 Liters
• Temp. Fluctuation：+,-0.3 Degree
• Color：Ivory
• Interior Chamber Material：SUS#304 Stainless Steel Plate
• Exterior Chamber Material：Stainless Steel Plate + Powder Coated
• Filters：HEPA Filters
• Indication Resolution：0.1degree , 1 Degree
• Heat up Time：30 Mins
• Transport Package：Strong Wood Carton
• Specification：TUV, ISO, SGS certification
• Trademark：Yuanyao
• Origin：China
• HS Code：9032100000
• Production Capacity：100 Sets,Month

SpecificationMODELYPO-072YPO-270YPO-480YOP-600YPO-720Internal Sim.WHD(mm)400×450×400600×900×500800×1000×6001000×1000×6001200×1000×600External Dim.W×H×D(mm)750×1100×5501150×1650×7401300×1700×8401500×1750×8401850×1750×840Temp.RangeRoom Temp.+10ºC---+200ºC(300ºC)FerformanceTemp.&Humi,Constancy±0.3ºCTemp.&Humi,Constancy±0.1ºC AT 200ºC;±1.5% AT 300ºCIndication Resolution0.1ºCHeat-up Time( min.)Approx.30min.Material Filters HEPA FiltersExterior and InteriorIron Sheet+Baked Enamel; SUS#304 stainless steel piateInsulationFiberglass WoolSYSTEMSCirulationCircle FanHeatingChrome Steel Strip Wire HeaterControllerElectric Digital Control+S.S.R.doorSingle-WingDouble-WingOther ComponentsEnvironmental Control Indicator Lights,Experiment Separation Shelves(2 pcs).Sevey DevicesOverheating Prevention Circuit breaker,Control System,Breakdown Indicator Light.Power Source[K.W.]AC 1Ψ 220V ; 3Ψ 380V 60/50Hz Customization of inner chamber size, temperature range, etc.
Except Industry dustfree high temperature test oven, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
