• Model NO.：HJ-66
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Unit of Strength：Kgf,N,Lbf
• Transfer Method：Servo Motor
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Display Digital Weight 0-100Kg Power Source AC220V Unit of Strength Kgf/N/Lbf Transfer Method Servo Motor Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product description
The packaging clamping force testing machine is used to simulate the influence of the clamping force of the two plywoods on the packaging and the goods when the clamping truck loads and unloads the packaging, and evaluates the clamping resistance strength of the packaging. It is suitable for kitchenware, furniture,
Packaging of home appliances, toys and other finished products, especially suitable for anti-pinch packaging
Strength test. Applies to all product packages tested during shipping or storage of product packages
The amount of deformation when the package is subjected to horizontal pressure and the ability of the package to protect the product in the package, so as to complete the
Good packaging design. According to the standard ASTMD6055 US SEARS or according to customer specified non-
Standard requirements are customized.


Lifting sample weight	Within 0-600KG (parallelepiped transport package)
LCD	The screen displays the large clamping force value, holding time, displacement, number of times
force accuracy	National Standard Level 1.6
Sensor Accuracy	1/20000, measurement accuracy 0.5%;
Upward displacement of the splint	0-1000mm (according to customer requirements) displacement accuracy is based on the ruler
Left and right stroke displacement of splint	0-1200mm (according to customer requirements)
Clamping plate size	1220*1220mm (can be customized according to customer requirements
Clamping test speed	Up and down 600mm/min; left and right 1-500mm/min (adjustable)
Unit of strength	Kgf/N/Lbf
Transfer method	Servo motor
Protective device	Leakage protection, travel limit device, overload protection, overvoltage protection, power failure protection, emergency stop device;
Splint force sensor	Four (the force transmitted by the more efficient and more sensitive induction clamp)
Machine splint	The thickness of the plywood is not less than 20mm to ensure that the clamping plate is not deformed under the clamping state (≤2000KG), the two plywood are parallel and perpendicular to the bottom plate, and high-quality non-slip rubber pads are used to ensure that the packaging samples are tested during the test. It is not easy to slip and be damaged during the process.
Machine size	2650*1900*2120mm
Voltage	AC220V/50HZ

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
