• Model NO.：HJ-69
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Test Aspects：Face, Edge, Angle
• Drive Mode：Motor Driven
• Accelerator：Pneumatic
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-69 Display Digital Weight 0-100Kg Power Source AC220V Test Aspects Face, Edge, Angle Drive Mode Motor Driven Accelerator Pneumatic Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

The zero drop tester is mainly used to assess the impact of the drop impact on the package during the actual transportation, loading and unloading process, and to evaluate the impact resistance of the package during the handling process and the rationality of the package design. The zero drop tester is mainly used for the drop test of larger packages. The machine uses an "E"-shaped fork that can move down quickly as a test piece bracket, and the test product is placed and balanced according to the test requirements (face, edge, corner test). During the test, the support arm moves downward at a high speed, and the test product falls to the base plate with the "E" type fork, and is embedded on the base plate under the action of the high-efficiency shock absorber. Theoretically, the zero drop tester can perform drop test from the zero height range, the drop height is set by the LCD controller, and the drop test can be performed automatically according to the set height.

Control principle: Adopting the rational design of imported computer, complete the design of free fall, edge, angle and surface


Maximum weight of test piece	0-100Kg can be customized)
Ddrop height	0-1500mm
Maximum specimen size	1000x1000x1000mm
Test aspects	face, edge, angle
Working power	380V/50HZ
Drive mode	motor driven
Protective device	The upper and lower are equipped with inductive protection devices
Impact plate material	45# steel, solid steel plate
Height display	touch screen control
Drop height indicator	Benchmark scale marking
Arm structure	45# steel, welded by square pass
Transfer method	Taiwan imported linear slider and copper guide bush, 45# chrome steel
Accelerator	pneumatic
Drop method	Electromagnetic and pneumatic integrated coordination
Weight	About 1500KG
Power	5KW

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
