• Model NO.：HJ-68
• Display：Digital
• Weight：0-100Kg
• Power Source：AC220V
• Unit：(Lines,Inch)
• Angle Display Method：LCD Display
• Precision：1%
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-68 Display Digital Weight 0-100Kg Power Source AC220V Unit (Lines/Inch) Angle Display Method LCD Display Precision 1% Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product use of carton sliding angle testing machine:
It is composed of test platform, motor, digital display inclinometer, braking device and control box, etc., with high control precision. Used to test the slip resistance of cartons. When beer boxes or other packaging boxes are stacked and transported, if the surface friction coefficient is large, it is easy to cause slippage. This machine test is used to improve the packaging slip resistance.

Design standard of carton sliding angle testing machine: according to DIN 53119-2-1997


Unit	(lines/inch)
Measuring range	0.1 degrees to 35 degrees
Angle display method	LCD display,
Inclination	±0.1 degree
Precision	1%
Incline speed	2°/sec
Drive mode	Electric
Lifting method	The screw drives the bracket to lift
Oblique dimension (L*W)	600*500mm
Machine size (L*W*H)	650*550*300mm
Weight	80KG
Power supply	220V, 1000W
Environmental conditions	10-30ºC, clean and less dust, no strong magnetic field, strong vibration source.

Features of carton sliding angle testing machine:
1. The frame is made of aluminum profiles, which is strong and beautiful. 2. It is driven by an ordinary, cheap and high-quality gear motor with a rectangular screw drive with a lightweight bearing seat. It is guided by double hard shafts and driven by synchronous pulleys. Display, adjust the upper and lower limits of the angle, it is very convenient to level the test platform and place the test product or test the product while swinging the angle. 4. There is a sliding frame on the test platform. Switch, so that the carton will not fall out during the sliding test and accurately draw the test from the top angle when it will slide!



FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
