Paperboard Bursting Test Instrument
Hangzhou Pnshar Technology Co., Ltd.- Type：Strength Testing Machine
- Weight：100-500Kg
- Power Source：AC220V
- Standards：ISO 2759, GB,T 1539, Qb,T 1057
- Video Link in Youtube：HTTP:,Youtu.Be,5c-Yvbx6jlc
- Transport Package：Wood Package, Free-Fumigation
Base Info
- Model NO.：PN-BSM600
- Specification：SGS, ISO
- Trademark：PNSHAR
- Origin：Hangzhou, Zhejiang
- HS Code：90248000
- Production Capacity：500sets,Year
Description
| No. | ITEM | SPECIFICATION |
| 1 | Power: | AC220V±10% 2A 50Hz |
| 2 | Measuring Range: | 300~5500kPa |
| 3 | Compression rate: | 170±15ml/min |
| 4 | Resolution: | 0.1kPa |
| 5 | Accuracy: | ≥ 99.5 % |
| 6 | Diaphragm size: | bulge height: 2.5±0.2mm |
| bulge diameter: 27.8mm | ||
| 7 | Diaphragm resistance: | When the bulge height is 10mm, the pressure is 170~220kpa |
| When the bulge height is 18mm, the pressure is 250~350kpa | ||
| 8 | Upper clamp: | 31.5±0.05mm |
| 9 | Lower clamp: | 31.5±0.05mm |
| 10 | Hydraulic transducer : | <6000kpa |
| 11 | Clamp pressure: | ≥690kpa |
