• Model NO.：HYCZ-1
• HS Code：90248000
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. HYCZ-1 HS Code 90248000 Production Capacity 100 Sets/Month

Product Description

Wheel Tracking Machine

Features:
1. This tester is used to test the high-temperature wheel rutting ability of asphalt mixture for the high-temperature stability performance of related mixing proportion design.
2.This tester is made with with an embedded WiFi, advanced single-chip microcomputer controlling technology,
machine fi nishing technology and related new developping application software.
3. Automaticly control temperature and time. Display displacement change, record the curve and print the result table automaticly.
4. Adopt absolute temperature sensor to collect temperature.
5. Adopt high precision displacement sensor and temperautre sensor.
6. This machine is equipped with one piece personal computer with Win-8 English operating system and one piece printer.



Model HYCZ-1
Heating Power: 3000W
Driving Motor Power: 750W
Electrical supply: 380V
Specimen size: 300x300x50mm or other require dimension
Working Method: crank connecting rod driven test wheel movement
Rubber wheel hardness: 84±4   international standard
Test wheel moving distance:  230mm±10mm
Load cycles:  26.5±1 cycles/min
Loading device: the contact pressure is0.7±0.05Mpa when the temperature is 60°C, total loading is around                                   78kg and adjustable
Deformation measurement precision: 0.3%
Temperature control precision: 0.5°C
Working temperature: 0~80°C    humidity≤90%, haven't corrosive and flammable gas
Weight:  500Kg
