• Model NO.：PN-JT500F
• Power Source：AC220V
• Standards：ISO1924,2
• Transport Package：Wood Package, Free-Fumigation.
• Specification：SGS, ISO, CE
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang
• HS Code：90248000
• Production Capacity：500sets,Year

Basic Info.

Model NO. PN-JT500F Power Source AC220V Standards ISO1924/2 Transport Package Wood Package, Free-Fumigation. Specification SGS, ISO, CE Trademark PNSHAR Origin Hangzhou, Zhejiang HS Code 90248000 Production Capacity 500sets/Year

Product Description

INSTRUCTION:
PN-JT500F box joint tensile tester is a tester designed and developed to detect the box joint strength of corrugated boxes according to the latest standard of TAPPI T813. There are three ways to join the corrugated boxes: adhesive, tape and nail. Box joining is the last step of corrugated carton forming. If the box joining tensile is poor, the carton will crack at the carton joint during loading, unloading, stacking and transportation, which will affect the compressive strength and appearance quality.
    The instrument adopts a vertical structure, the clamp spacing can be freely set within a certain range, the stretching stroke is large, and it is a mechatronic product. It adopts modern mechanical design concepts and ergonomic design guidelines, and uses advanced high-speed ARM processing. The device is made with careful and reasonable design, and the display uses a more stylish and convenient touch screen. It is a new-generation instrument for measuring the bonding force of a new-generation carton box with novel design, convenient use, excellent performance, and beautiful appearance.
APPLICATIN:
Corrugated box

SPECIFCATION:

ITEM	SPECIFICATION
Power supply:	AC (100~240)V  2A  50/60Hz;
Indicator error:	±1%;
Indication offset:	< 1%;
Resolution:	0.01N;
Measure range:	(5~500)N;
Deformation error:	≤±1 mm
Clamp width:	25mm;
Working stroke:	(20~350)mm;
Testing speed:	(25±5)mm/min (can be set in 1~500mm/min)
Back speed:	(5~500)mm/min;
Display:	5" color touch screen;
Printer:	Thermal printer;
Output:	RS232(Standard)/USB(Optional);
Conditions:	Temperature(20±10)ºC,Humidity<85%;
Dimension:	(495×355×925)mm(L×W×H);
Net Weight:	53kg.

FEATURES:
It adopts new module circuit design and has WIFI  function. After networking, the test results can be saved to the cloud server, which can be queried and generated reports through the dedicated QMS quality management system;
Adopt the design of mechatronics, and test with one click
The test speed and clamp distance can be set, and it only needs to be set once. The next time you place a sample to test directly;
With data statistics function, display average, maximum, minimum, standard deviation and deformation;
Built-in thermal printer, can print test report directly after testing a batch of data.
Display information such as joint force and deformation in real time;
Can be connected to computer software, with real-time display pressure curve function and data analysis management, saving, printing and other functions.
