• Model NO.：HTPV-08ZH
• Weight：500-1000Kg
• Power Source：AC220V
• Product Name：Low Temperature Dynamic Mechanical Load Testing Ma
• Certificate：ISO SGS
• Material：Stainless Steel and Aluminum Alloy
• Delivery：30 Work Days
• Packages：Wooden Case
• Warranty Time：One Year
• Transport Package：Strong Wooden Case
• Specification：According to customer requirement
• Trademark：HOTOTECH
• Origin：Dongguan China
• HS Code：9013809000
• Production Capacity：100 Set Per Month

Basic Info.

Model NO. HTPV-08ZH Weight 500-1000Kg Power Source AC220V Product Name Low Temperature Dynamic Mechanical Load Testing Ma Certificate ISO SGS Material Stainless Steel and Aluminum Alloy Delivery 30 Work Days Packages Wooden Case Warranty Time One Year Transport Package Strong Wooden Case Specification According to customer requirement Trademark HOTOTECH Origin Dongguan China HS Code 9013809000 Production Capacity 100 Set Per Month

Product Description

Low temperature dynamic Mechanical Load Testing machine
verification and ensure component under the different install angle suffer wind ,snow,or cover ice etc static ,dynamic load ability.width use to check PV component resistance press strength test , adopt dynamic holding press technical , simulate load test, in order to products under the load statue resistance press ability.


Low temperature dynamic Mechanical Load Testing machine specificaitons
1.Machine table exterior size:L 320 × D 180 × H 195 cm
2.Test positive load the max 2400 Pa,negative load the max 2400 Pa
3.Aluminum extrusion structure , platform and support under the test suffer the force statue not deformation ( aluminum surface with the paint dealing , ensure its not discolor)
4.Customization test platform clamp , can according to the pending specimen install method to do the adjust )
5.The max test size 120 × 240cm (can adjust)
6 .  Calibrator:350 kg
7 .DC constant voltage and current power :0~100Vor 0~15A adjustable;the resolution 0.001V or 0.001A;the voltage setting accurate more than 0.1V,current setting value accurate more than 0.1A.
8..Cylinder number:4 groups, in total 8 pcs
Cylinder outside diameter 80mm
Pneumatic cylinder single the max pressure > 6 bar
Pneumatic cylinder single group the max put out force > 300 kg
Pneumatic cylinder stretch stroke:150 mm
9.sucker number 8 groups , in total 32 PCS
Sucker diameter:120 mm
Every pneumatic attach a vacuum pressure monitor
Between the two suckers mid point  spacing can adjust 120mm~ and 400mm
10.Running environment : 0ºC , -20ºC , -40 ºC


Company Introduction
  Dongguan HongTu Instrument Co.,Ltd specilizes in develooping and producing testing machines for PV module   We are the largest testing machine manufacturer in China. we treasure the value of good quality , reasonable price and efficient service with customer satisfaction . we expert oursleves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit
  Please feel free to contact us for any enquires from our wide range of products
