MOA Lightning Arrester Leakage Current Tester for 10kV Power System
HV Hipot Electric Co., Ltd.- Power Supply：0-30kv Current: 0-1000mA.
- Resolution：Voltage: 0.1 Kv; Current: 0.5 Micro-AMP
- Built-in Power Charge Time：2-3 Hours
- Built-in Power Usage Time：>=4 Hours
- Ambient Temperature：-10~ 50degree
- Relative Humidity：25degree, <=85%
Base Info
- Model NO.：GDYZ-30D
- Power Frequency：50+,-1Hz
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：5000PCS,Year
Description
Basic Info.
Model NO. GDYZ-30D Power Frequency 50+/-1Hz Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 5000PCS/YearProduct Description
GDYZ-30D zinc oxide arrester tester is specifically designed to test the electric valve inner defects of zinc oxide lightning arrester for 10KV and below power system.
This device combined DC high voltage power supply with measure&control system, which size is smaller and weight is more lighter. It is an essential equipment for power system and Zinc Oxide lightning arrester manufacturer.
Features
Power supply: AC220V AC, or built-in rechargeable battery.
Easy to use: Visual measurement data display.
Measuring accuracy: All-digital processing, built-in sophisticated mathematical models, high accuracy, good repeatability of test results.
Light weight, easy to carry.
Technical parameters
| Measuring range | Voltage: 0-30kV; Current: 0-1000mA |
| Resolution | Voltage: 0.1 kV; Current: 0.5 micro-AMP |
| Built-in power charge time | 2-3 hours. |
| Built-in power usage time | ≥4 hours |
| Ambient temperature | -10~ 50degree |
| Relative humidity | (25degree) <=85% |
| Altitude | <1000m |
| Supply voltage | 220V+/-10% |
| Power frequency | 50+/-1Hz |
