Load Ring Penetrometer Proving Ring Penetrometer
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Transport Package：Wooden Package
- Trademark：C-Tech
- Origin：China
Base Info
- Model NO.：33-T0166
- HS Code：90248000
- Production Capacity：10000 PCS,Year
Description
Basic Info.
Model NO. 33-T0166 HS Code 90248000 Production Capacity 10000 PCS/YearProduct Description
Proving Ring Penetrometer/ Load Ring Penetrometer
The Proving Ring Penetrometer is a 30 degree cone penetrometer used to determine the bearing capacity of subgrades or to measure soil compaction. The penetrometer also serves as a rapid means of determining the penetration resistance of soil in shallow exploration work.
- Used for measuring the bearing strength and compaction degree of soils. The apparatus consists of a "T" shaped handle connected to a load ring 1 kN (100 kgf) cap., with max load pointer, and of an extension rod with five 100 mm graduations. The 30° end cone has an area of 645 mm2 (I sq. in). Supplied complete with calibration chart.
- Weight approx.: 4 kg
| Proving Ring | 250 lb. (1.1kN) capacity |
| Dial Indicator | Brake type |
| Shaft | 3/4" (19mm) diam. x 18" l. (457mm); graduated at 6" (152mm) intervals |
| Extension rod | 3/4" (19mm) diam. x 36" i. (914mm); graduated at 6" (152mm) intervals |
| Cone | 30 degree; 1 sq. in.; replaceable |
| Handle | Cast aluminum |
| Weight | Net 12 lbs. (5.4 kg). |
