Oxidation Stability Tester for Insulating Oils ASTM D2440
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.Base Info
- Model NO.:GD-2440
- HS Code:9031809090
- Production Capacity:100sets,Month
Description
Basic Info.
Model NO. GD-2440 HS Code 9031809090 Production Capacity 100sets/MonthProduct Description
Oxidation Stability Tester for Insulating Oils ASTM D2440Features:
- The ASTM D2440 Oxidation Stability Tester is desktop, including heating bath and flow meter. The stainless steel lid has holes which can be put into the sample bottle.
- Stainless steel structure with ceramic coating.
- Environmentally friendly metal bath heating, reduce the harm of oil fumes to the human body, high efficiency thermal insulation effect.
- Stainless steel heater.
- The Oxidation Stability Tester is equipped with very precise electronic flowmeter.
- Air filter with glass wool.
- The controller purification system includes a sodium hydroxide bottle, a sulfuric acid cleaning bottle and a safety bottle.
- It adopts the imported Omron PID thermostat, digital display temperature, accuracy is 0.1ºC.
- Safety measures to prevent overheating or low liquid level.
Application:
- Insulating oil manufacturer
- Related testing department
Reference Standards:
- ASTM D2440 Standard Test Method for Oxidation Stability of Mineral Insulating Oil
- IEC 61125 Test method for evaluating the oxidation stability of insulating liquids in the delivered state.
- NB/SH/T 0811 Unused hydrocarbon-based insulating liquids. Test methods for evaluating the oxidation stability.
Technical Parameters:
Model No. | GD-2440 Oxidation Stability Tester |
Applicable standards | NB/SH/T0811, ASTM D2440, IEC 61125 |
Temperature control method | Imported PID digital display thermostat |
Temperature control accuracy | room temperature~200±0.1ºC |
Heating method | Metal bath heating |
Flow control | Precision electronic flowmeter |
Working unit | 4 tubes |
Timing method | Digital display timer |
Power supply | AC220V/50Hz |
Total power | 2.5KW |
Dimensions | 430mm*540mm*630mm |
Net weight | 32KG |
ASTM D2440 Oxidation Stability Tester of Mineral Insulating Oil:
